| Part Number | 0990-9396.1D |
|---|---|
| Manufacturer | Texas Instruments (TI) |
| Category | Integrated Circuits (ICs) > Automotive ICs – ABS Automotive Control Microcontroller |
| Description | Automotive-grade high-reliability ABS control microcontroller IC, dedicated for vehicle anti-lock braking system ECU, with robust EMC performance, wide temperature tolerance and built-in safety diagnostic logic for automotive chassis control. |
| Stock Status | In Stock |
| Origin | Original Factory |
Product Overview
The 0990-9396.1D is a high-reliability automotive ABS master microcontroller developed by Texas Instruments, specially customized for vehicle anti-lock braking ECU control systems. This automotive-grade SoC integrates multi-channel signal acquisition logic, real-time brake pressure calculation algorithm unit, vehicle speed signal processing circuit and complete fault self-diagnosis module. It passes strict AEC-Q100 automotive reliability certification, with strong anti-interference ability to cope with complex electromagnetic environment inside vehicle cabins. Optimized low-power operation mode reduces vehicle standby power consumption, while the built-in hardware safety mechanism effectively avoids single-point failure of braking control. Compact standard automotive chip packaging simplifies PCB layout of brake control unit, widely used in passenger car and commercial vehicle ABS electronic control unit design, with stable long-term operation performance under extreme cold and high temperature vehicle working conditions.
Core Advantages
Automotive AEC-Q100 Qualified Reliability
Fully compliant with AEC-Q100 Grade 1 automotive reliability standard, supporting wide vehicle operating temperature range, resisting vibration, humidity and electromagnetic interference inside automobile cabin, suitable for long-term vehicle chassis working environment.
Integrated Dedicated ABS Control Hardware Logic
Built-in dedicated wheel speed signal processing peripheral, brake pressure closed-loop control accelerator and real-time fault diagnosis circuit, reducing peripheral chip matching quantity and simplifying ECU hardware design difficulty.
High EMC Anti-Interference Performance
Optimized internal power supply isolation and signal shielding design, effectively suppress vehicle high-voltage ignition, motor switching and other electromagnetic noise interference, ensure stable brake control signal output.
Built-In Functional Safety Diagnostic Unit
Integrated hardware self-test and real-time monitoring circuit, automatically detect chip operation abnormality, sensor signal loss and circuit short-circuit fault, output fault code to meet automobile functional safety regulatory requirements.
Key Specifications
| Brand | Texas Instruments (TI) |
|---|---|
| RoHS Status | RoHS Compliant Standard |
| EDA/CAD Model | 3D Model & PCB Footprint Available upon request |
| Warranty | 1-Year Standard Factory Warranty |
| Package / Case | QFP-100 Package |
| Mounting Type | Surface Mount Technology (SMD/SMT) |
| Surface Marking / Silkscreen | 0990-9396.1D Marking |
| Module Function Type | Automotive ABS Anti-Lock Braking System Control Microcontroller |
| Rated Operational Voltage | Standard 12V Vehicle On-Board Power Supply Matching |
| Insulation Resistance | Automotive Standard High Isolation Internal Power Design |
| Terminal Interface Type | Multi-Pin SMD Signal & Power Integrated Pins |
| Housing Flammability Rating | Automotive Grade Flame Retardant Plastic Packaging Material |
| Shock Resistance Rating | Meet ISO 16750 Vehicle Vibration & Shock Test Standard |
| Operating Temperature Range | -40°C to +125°C (AEC-Q100 Grade 1 Automotive Envelope) |
Typical Applications
- Passenger Car & Commercial Vehicle ABS Anti-Lock Braking ECU Controller
- Vehicle ESC Electronic Stability Control Chassis Control Unit
- Automotive Wheel Speed Signal Acquisition & Brake Force Regulation Module
- New Energy Vehicle Chassis Safety Control Electronic Assembly
- Automotive Aftermarket Refitted Brake Control System & Test Bench Equipment
Order & Shipping Info
| Minimum Order Quantity (MOQ) | 1 Piece |
|---|---|
| Shipping Time | Shipped within 1-2 business days |
| Delivery Time | 3-7 working days worldwide |
| Shipping Methods | DHL, UPS, FedEx, EMS |
| Payment Methods | T/T (Bank Transfer), PayPal, Credit Card, Western Union |
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
Frequently Asked Questions
Q1: Is your current stock inventory of the 0990-9396.1D fully original TI automotive chip?
A: Yes, we guarantee that all 0990-9396.1D chips in our stock are 100% brand-new, factory-original Texas Instruments automotive-grade products, stored under professional anti-static and constant temperature warehouse standards.
Q2: Can this chip work stably in high temperature engine cabin environment?
A: This model is AEC-Q100 Grade 1 certified, supporting operating temperature range from -40°C to +125°C, it can long-term stable operation inside vehicle engine compartment and chassis closed ECU housing.
Q3: Does this microcontroller integrate complete ABS algorithm peripheral circuits?
A: Yes, it has dedicated wheel speed signal capture interface, brake pressure closed-loop control unit and real-time fault diagnosis hardware, which can greatly reduce the number of peripheral matching components for ABS ECU development.
Q4: How can our engineering group request full datasheet, pinout diagram, or bulk order quotation?
A: Please complete our Quick Inquiry web form on this page with details about your processing parameters. Our application support desk will process your inquiry and dispatch the available technical documentation package within 24 hours.
