10CL025YE144I7G
10CL025YE144I7G
| Part Number | 10CL025YE144I7G |
|---|---|
| Manufacturer | Intel (Formerly Altera) |
| Category | Integrated Circuits (ICs) > Embedded – FPGAs (Field Programmable Gate Array) |
| Description | Cyclone 10 LP Low-Power FPGA, 24,624 Logic Elements, 608 Kbits RAM, 66 Multipliers, 76 User I/Os, 1.2V Core, Industrial Grade (-40°C to +100°C), 144-EQFP Package. |
| Stock Status | In Stock |
| Origin | Original Factory |
Product Overview
The 10CL025YE144I7G is an ultra-low-power FPGA of Intel Cyclone 10 LP series (formerly Altera). Optimized for cost-sensitive, low-power scenarios, it integrates 24,624 LEs, 608 Kbits M9K embedded RAM and 66 dedicated 18×18 multipliers. Equipped with 76 programmable I/Os supporting multi-voltage interfaces including LVDS, this 144-EQFP industrial-grade device (-40℃~+100℃) suits industrial automation, smart grid, automotive and edge IoT applications.
Core Advantages
Optimized Ultra-Low Power Consumption
1.2V core voltage architecture lowers static & dynamic power for power-limited embedded systems.
Integrated DSP & Embedded RAM Resources
Built-in multiplier and M9K RAM blocks support high-speed signal processing, data buffering and hardware algorithm operation.
Thermally Enhanced EQFP Package
144-EQFP with exposed pad offers good heat dissipation, simplifying PCB layout without complex BGA manufacturing.
Industrial-Grade Reliability & Complete Tool Support
Wide industrial temperature range, fully compatible with Intel Quartus software for fast compilation and IP deployment.
Key Specifications
| Brand | Intel / Altera Cyclone 10 LP Series |
|---|---|
| RoHS Status | RoHS Compliant / Lead-Free / Green Package (G Suffix) |
| EDA/CAD Model | Schematic symbol models, 3D CAD step profiles, and 144-EQFP footprint land patterns are available on request |
| Warranty | 1-Year Standard Quality Warranty |
| Package / Case | 144-EQFP (20.00 mm × 20.00, 0.50 mm Pitch) |
| Mounting Type | Surface Mount (SMT / SMD) |
| Surface Marking / Silkscreen | 10CL025YE144I7G / Intel logo, Marking |
| Logic Elements (LEs) | 24,624 Logic Elements |
| Total RAM Bits | 608,256 Bits (~608 Kbits, 66 M9K Blocks) |
| Embedded Multipliers (18×18) | 66 Dedicated Multipliers |
| Phase-Locked Loops (PLLs) | 4 General-Purpose PLLs |
| Number of User I/Os | Up to 76 Programmable I/O Pins |
| Core Supply Voltage (VCCINT) | 1.2V Core Logic Rail |
| Operating Temperature Grade | Industrial Grade (-40°C to +100°C Junction Temperature TJ) |
| Logic Array Blocks (LABs) | 1,539 LABs |
| Moisture Sensitivity Level (MSL) | Level 3 (168 hours) |
| Packaging Form | Tray, 60 units per standard tray |
Typical Applications
- Industrial control systems, Programmable Logic Controllers (PLCs), and multi-axis motor control drives
- Smart grid energy monitors, power distribution units, and solar inverter controllers
- Automotive infotainment gateways, sensor aggregation units, and driver assistance interface units
- Commercial displays, LED matrix drivers, and protocol converters (SPI, UART, CAN, Ethernet bridging)
- Medical diagnostics instrumentation, portable testing equipment, and Internet of Things (IoT) edge computing nodes
Order & Shipping Info
| Minimum Order Quantity (MOQ) | 1 Piece |
|---|---|
| Shipping Time | Shipped within 1-2 business days |
| Delivery Time | 3-7 working days worldwide |
| Shipping Methods | DHL, UPS, FedEx, EMS |
| Payment Methods | T/T (Bank Transfer), PayPal, Credit Card, Western Union |
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
Frequently Asked Questions
Q1: What do the individual alphanumeric codes in “10CL025YE144I7G” represent?
A: “10CL” identifies the Cyclone 10 LP low-power family, “025” denotes 24,624 logic elements, “Y” specifies a 1.2V core supply rail, “E” represents the EQFP package type, “144” specifies the pin count, “I7” designates industrial temperature grade (-40℃ to +100℃) with speed grade 7, and “G” confirms lead-free RoHS-compliant construction.
Q2: Which software toolchain supports designing and programming the 10CL025YE144I7G?
A: The 10CL025YE144I7G is fully supported by Intel Quartus Prime Design Software (Lite, Standard, or Pro Edition). Designers can perform synthesis, placement and routing, timing analysis, and generate programming files using VHDL or Verilog HDL.
Q3: How does the 10CL025YE144I7G store its configuration memory upon power-off?
A: Like most SRAM-based FPGAs, the configuration memory is volatile. Upon power-up, it automatically loads its configuration bitstream from an external non-volatile Serial Flash memory IC (such as EPCQ or EPCS series) via Active Serial (AS) mode, or via JTAG / Passive Serial (PS) modes.
Q4: What power supply rails are needed on the PCB for this FPGA?
A: The chip requires a 1.2V core supply (VCCINT), a 2.5V phase-locked loop supply (VCCA), and bank-dependent I/O supply voltages (VCCIO) configurable from 1.2V to 3.3V according to peripheral logic level requirements.
Q5: What is the operating temperature range of 10CL025YE144I7G?
A: It is industrial grade device, operating temperature range: -40℃ ~ +100℃.
Q6: Does this FPGA support LVDS differential signal interfaces?
A: Yes, partial I/O banks support LVDS differential interfaces, suitable for high-speed data transmission design.
Q7: Can I get samples of 10CL025YE144I7G? How about delivery time?
A: Samples are available on request. Please submit inquiry form to confirm inventory, lead time and bulk price.
