AD1939YSTZRL
AD1939YSTZRL
| Part Number | AD1939YSTZRL |
|---|---|
| Manufacturer | Analog Devices Inc. (ADI) |
| Category | Integrated Circuits (ICs) > ADC/DAC – Special Audio CODECs |
| Brief Description | 4 ADC/8 DAC, 192 kHz, 24-bit audio codec with integrated PLL, LQFP-64 tape & reel packaging for SMT mass production |
| Stock Status | In Stock |
| Origin | Original Factory |
Product Overview
The AD1939YSTZRL is a high-performance multi-channel audio CODEC by ADI, integrating 4 differential ADC inputs, 8 differential DAC outputs and an on-chip PLL. It supports 24-bit PCM audio up to 192kHz sampling rate via Sigma-Delta architecture, with dual SPI/I2C control bus and full differential analog paths to suppress EMI noise. Suitable for automotive audio, professional recording and home theater systems; RL suffix stands for tape & reel packaging for mass SMT production.
Core Advantages
High Channel Integration + Built-in PLL Clock
Combines 4 ADC + 8 DAC on single chip; integrated PLL removes external high-frequency crystal, saving PCB space and clock synchronization workload.
Industry-Leading Audio Dynamic Range
ADC typical 107dB (min 105dB), DAC typical 112dB (min 110dB) A-weighted dynamic range for high-fidelity audio playback.
Full Differential Analog Signal Path
Differential I/O design strongly rejects EMI interference, fit for noisy automotive & industrial mixed-signal circuits.
Dual SPI & I2C Control Interface
Dual serial bus supports flexible register configuration, independent channel volume tuning and clickless mute.
Key Specifications
| Brand | Analog Devices Inc. (ADI) |
|---|---|
| On-Chip PLL Clock Generator | Integrated master clock PLL, derives reference clock from LRCLK signal, removes external high-frequency crystal oscillator requirement |
| RoHS Status | RoHS Compliant / Lead-Free / Halogen-Free Materials Sourced (“Z” Suffix Certified) |
| EDA/CAD Model | 3D STEP Models, Schematic Symbols, and PCB footprints available upon request |
| Warranty | 1-Year Standard Global Quality Warranty |
| Package / Case | 64-LQFP (10mm × 10mm × 0.50mm) |
| Packaging Format | Tape & Reel (RL suffix), for automatic SMT pick-and-place mass production |
| Mounting Type | Surface Mount Technology (SMD/SMT Lead Reflow Solder) |
| Surface Marking / Silkscreen | AD1939YSTZ Marking |
| Resolution & Digital Audio Interface | 24-Bit Linear PCM Data Depth with standard TDM, I²S, Left-Justified & Right-Justified audio layout support |
| Maximum Sampling Rate | 8kHz ~ 192 kHz High-Resolution Audio Processing Capabilities |
| ADC Channels & Dynamic Range | 4-Channel Differential Analog Inputs, Typical 107 dB Dynamic Range (A-Weighted, min guaranteed 105dB) |
| DAC Channels & Dynamic Range | 8-Channel Differential Analog Outputs, Typical 112 dB Dynamic Range (A-Weighted, min guaranteed 110dB) |
| Total Harmonic Distortion (THD+N) | Typical -94 dB for ADCs and DACs under nominal operation, optimal performance reaches -96dB |
| Digital Power Rail Input (VDD) | 3.3V Nominal Supply Voltage Domain, Tolerant to 5V logic input signals |
| Analog Power Rail Input (VCC) | 3.3V Standard Audio Operational Power Boundary |
| Supply Current | Analog supply typical 32mA, Digital supply typical 18mA at full operation sampling rate 192kHz |
| Input Analog Full-Scale Level | 2.2 V rms differential full-scale analog input voltage range |
| Output Analog Full-Scale Level | 2.2 V rms differential full-scale analog output voltage swing |
| Digital I/O Logic Level | 3.3V LVCMOS standard, 5V tolerant input pins |
| Channel Sample Interleave Mode | TDM 8-channel / TDM 16-channel time division multiplex audio data transmission supported |
| Audio Clock Input Source | LRCLK external frame clock input, internal PLL generates all required audio master clocks |
| Operating Temperature Range | -40°C to +105°C (Standard ambient operating temp for automotive/industrial use; Max case temperature -40~+125°C) |
| Control Communication Interface | Dual SPI 4-wire + I²C serial control bus for register configuration |
Typical Applications
- Premium Automotive Infotainment, Multi-Channel Car Amplifiers, Active Noise Cancellation Equipment
- Professional Studio Recording Consoles, Audio Effects Processors, PA Public Address Systems
- High-End Home Theater Receivers, Surround Sound Decoders, Audiophile Media Players
- Multi-Zone Distributed Audio Matrices, Broadcast Audio Workstations
- Industrial Acoustic Test Equipment, Vibration & Audio Signal Analysis Instruments
Order & Shipping Info
| Minimum Order Quantity (MOQ) | 1 Piece |
|---|---|
| Processing Lead Time | Ship within 1–2 working days after payment confirmation |
| Global Delivery Time | 3–7 working days via international express |
| Shipping Carriers | DHL, UPS, FedEx, EMS |
| Accepted Payment Methods | T/T Wire Transfer, PayPal, Credit Card, Western Union |
Technical Support
Submit inquiry to get datasheets, engineering samples, bulk pricing and pinout docs. Our technical sales reply within 24 hours worldwide.
Frequently Asked Questions
Q1: Are AD1939YSTZRL genuine new original?
A: All stock are brand-new original from ADI, shipped in anti-static tape & reel. Every batch passes pin & visual inspection before delivery.
Q2: What does RL suffix mean?
A: RL stands for tape & reel for automated SMT mass production. AD1939YSTZ (without RL) is tray packaging for prototype sampling.
Q3: Can it work without external master crystal?
A: Yes. The built-in PLL generates all audio clocks from LRCLK, no external high-frequency crystal needed.
Q4: How to get datasheet and bulk quotation?
A: Fill the inquiry form with your project demand and order quantity, we will send datasheet, pinout diagram and tiered price within 24h.
