AD5601BKSZ-REEL7
Basic Information
| Part Number | AD5601BKSZ-REEL7 |
|---|---|
| Manufacturer | Analog Devices Inc. |
| Category | Data Acquisition – Digital to Analog Converters (DAC) |
| Description | 8-Bit NanoDAC, I2C Interface, Single Channel, 2.7V-5.5V Supply, SC70-5, Tape & Reel Package |
Product Overview
The AD5601BKSZ-REEL7 is a low-power, single-channel 8-bit digital-to-analog converter (DAC) featuring an I2C-compatible serial interface, designed for portable, battery-powered, and space-constrained industrial and consumer applications. This device operates from a 2.7V to 5.5V supply voltage with ultra-low power consumption, providing fast settling time and high precision voltage output. Integrated power-on reset functionality ensures reliable system initialization, while the compact SC70-5 package supports high-density PCB designs. Supplied in tape and reel format for automated manufacturing, it delivers stable performance across the extended industrial temperature range.
Key Specifications
| Parameter | Value |
|---|---|
| RoHS | Compliant (Lead-Free, Halogen-Free) |
| EDA/CAD Models | Available (Symbol, Footprint, 3D STEP, Schematic) |
| Warranty | 3 Years Standard Warranty |
| Brand | Analog Devices Inc. (ADI) |
| Resolution | 8 Bits |
| Number of Channels | 1 |
| Interface Type | I2C Serial Interface |
| Supply Voltage | 2.7V to 5.5V |
| Settling Time | 4.5µs (Typical) |
| Operating Temperature Range | -40°C to +125°C |
| Package Type | SC70-5 |
| Packaging | Tape & Reel (REEL7) |
Typical Applications
- Portable and Battery-Powered Electronic Devices
- Precision Voltage Generation and Calibration Systems
- Sensor Signal Conditioning and Adjustment
- Industrial Process Control and Automation
- Wearable Devices and Consumer Electronics
- Test, Measurement, and Data Acquisition Equipment
- Automotive Control and Sensor Modules
- Closed-Loop Control and Servo Systems
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
