AD7928BRUZ-REEL7
AD7928BRUZ-REEL7
| Part Number | AD7928BRUZ-REEL7 |
|---|---|
| Manufacturer | Analog Devices |
| Category | Analog-to-Digital Converters (ADC); 12-Bit 8-Channel ADC |
| Description | 12-Bit 8-Channel Serial ADC, 1 MSPS, 2.7V-5.25V, SPI Interface, TSSOP-16 Package |
Product Overview
The AD7928BRUZ-REEL7 is a low-power, high-speed 12-bit analog-to-digital converter featuring 8 single-ended analog input channels and a fast SPI-compatible serial interface. It delivers up to 1 MSPS conversion speed with excellent linearity and low noise performance, operating over a wide supply range of 2.7V to 5.25V for flexible system integration. The device includes a built-in 2.5V reference (optional external reference), channel sequencer, and shutdown mode for power optimization, making it ideal for multi-channel data acquisition, industrial control, and portable measurement applications. Housed in a compact TSSOP-16 surface-mount package, it supports space-constrained designs and industrial-grade reliability.
| Key Specifications | |
|---|---|
| RoHS Status | RoHS Compliant |
| EDA / CAD Models | 3D Model, Symbol, Footprint Available |
| Warranty | 2-Year Warranty |
| Brand | Analog Devices |
| Resolution | 12 Bits |
| Input Channels | 8 Single-Ended Channels |
| Sampling Rate | 1 MSPS (Maximum) |
| Interface | SPI Serial Interface |
| Supply Voltage | 2.7V ~ 5.25V |
| Package Type | TSSOP-16 (Surface Mount) |
| Operating Temperature | -40°C to +125°C |
Typical Applications
- Multi-Channel Data Acquisition Systems
- Industrial Process Control & Monitoring
- Portable Measurement Instruments
- Sensor Signal Conditioning & Digitization
- Automotive Control Systems
- Power Management & Monitoring
- IoT & Wireless Sensor Nodes
- Embedded System Analog Input Modules
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
