ADG508ATQ/883B
ADG508ATQ/883B
| Part Number | ADG508ATQ/883B |
|---|---|
| Manufacturer | Analog Devices Inc. (ADI) |
| Category | Integrated Circuits (ICs) > Interface – Analog Switches, Multiplexers, Demultiplexers |
| Description | Military-grade, 8-channel CMOS analog multiplexer, fully compliant with MIL-STD-883 class B standards. |
| Stock Status | In Stock |
| Origin | Original Factory |
Product Overview
The ADG508ATQ/883B is a high-reliability, monolithic CMOS 8-channel analog multiplexer manufactured by Analog Devices Inc., precisely screened to MIL-STD-883 Class B military standard specifications. This device switches one of eight inputs to a common output based on the state of a 3-bit binary address. Fabricated using an advanced proprietary linear compatible CMOS (LC2MOS) process, the ADG508ATQ/883B provides low power dissipation while offering high switching speeds and low on-resistance traits. It features fully latch-up proof construction and includes embedded overvoltage protection structures. Housed in a hermetically sealed 16-pin ceramic DIP package, this high-performance multiplexer is optimized for severe-environment data acquisition networks, aerospace avionics instrumentation, and high-integrity defense electronic systems.
Core Advantages
Military Grade & MIL-STD-883 Compliant
Fully certified and rigorously screened per MIL-STD-883 Method 1008 Class B. It delivers superior reliability, traceable electrical parameters and excellent package hermeticity, ideal for high-reliability military and defense applications.
Low Power Consumption
Built with advanced LC2MOS process technology, the device features microampere-level quiescent current. It helps reduce heat generation in densely packed modules and battery-powered defense equipment.
Robust Latch-Up Proof Performance
Designed with protective guard rings to separate internal NMOS and PMOS transistors. It effectively prevents latch-up issues even under signal overvoltage and transient voltage spikes.
High Speed & Low Distortion Switching
It features fast switching speed and stable on-resistance across the full signal range. The device maintains clear analog signals with minimal distortion for high-precision measurement systems.
Key Specifications
| Brand | Analog Devices Inc. |
|---|---|
| RoHS Status | Non-RoHS / Lead-Based (Military Standard) |
| EDA/CAD Model | 3D Model & PCB Footprint Available upon request |
| Channel Configuration | 8-Channel Analog Multiplexer (8:1) |
| Logic Compatibility | TTL and CMOS Digital Input Compatible |
| Supply Voltage Range | ±10.8V to ±16.5V Dual Supplies, or +10.8V to +16.5V Single Supply |
| Operating Temperature Range | -55°C to +125°C (Extended Military Grade Profile) |
| Package / Case | CDIP-16 Hermetically Sealed Ceramic |
| Surface Marking / Silkscreen | ADG508ATQ Marking |
| Screening Level | MIL-STD-883 Class B Military Screening |
Typical Applications
- Aerospace Flight Control Electronics and Defense Avionics Systems
- Military Radars, Sonar Processing, and Secure Tactical Communications
- High-Accuracy Remote Data Acquisition and Multichannel Telemetry Blocks
- Automatic Test Equipment (ATE) and Precision Electronic Instruments
- Severe Environment Industrial Controls and Geophysical Logging Equipment
Order & Shipping Info
| Minimum Order Quantity (MOQ) | 1 Piece |
|---|---|
| Shipping Time | Shipped within 1-2 business days |
| Delivery Time | 3-7 working days worldwide |
| Shipping Methods | DHL, UPS, FedEx, EMS |
| Payment Methods | T/T (Bank Transfer), PayPal, Credit Card, Western Union |
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
Frequently Asked Questions
Q1: Is your stock of ADG508ATQ/883B completely genuine and original?
A: Yes, we guarantee that all ADG508ATQ/883B parts are 100% authentic, brand-new components from Analog Devices, processed in strict adherence to MIL-STD-883 standards, and packaged in factory-sealed hermetic tubes.
Q2: What is the significance of the “/883B” suffix code in the part number?
A: The “/883B” code signifies that the device has undergone comprehensive environmental, electrical, and mechanical stress test procedures according to MIL-STD-883 Class B requirements, making it fully approved for high-reliability military and aerospace uses.
Q3: Can this device be powered using a single voltage power supply rail?
A: Yes, while optimized for standard high-performance dual-rail setups (e.g., ±15V), the ADG508ATQ/883B can operate reliably on a single-supply rail configuration spanning from +10.8V to +16.5V.
Q4: How can our design engineers obtain the full structural military layout data sheets and verification details?
A: Please complete our Quick Inquiry web form, and our defense-grade product application engineering specialists will respond with the required PDF data and compliance sheets within 24 hours.
