ADS1216Y/2K
ADS1216Y/2K
| Part Number | ADS1216Y/2K |
|---|---|
| Manufacturer | Texas Instruments (TI) |
| Category | ICs > Data Acquisition > Analog-to-Digital Converters (ADC) |
| Short Description | 24-bit high precision delta-sigma ADC, 8-channel multiplexer, built-in PGA, 2.5V reference and SPI interface, 48-TQFP tape reel package |
| Stock Status | In Stock |
| Origin | Original Factory |
Product Overview
The ADS1216Y/2K is a 24-bit delta-sigma ADC designed for high-precision measurement equipment. It supports 8 differential or 8 single-ended input channels, integrates a programmable gain amplifier, 2.5V reference and excitation current sources to simplify sensor circuit design. Equipped with 4-wire SPI interface and on-chip RAM for calibration data, this industrial-grade ADC works from -40°C to 85°C, supplied in 2000pcs tape reel TQFP packaging.
Core Advantages
High Resolution & Low Distortion
24-bit lossless conversion with typical INL of ±0.0015% FS, stable sampling up to 780SPS for tiny sensor signal capture.
All-In-One Analog Frontend
Built-in 1~128x PGA, multi-channel MUX, 2.5V voltage reference and programmable IDAC current sources, greatly reducing external components.
Flexible Digital Design
Standard SPI bus supports daisy chain connection; on-chip RAM stores user calibration parameters, with 8 GPIO pins for peripheral control.
Wide Industrial Compatibility
2.7V~5.25V dual analog/digital supply, -40℃~85℃ operating temperature, fully RoHS compliant for industrial and medical equipment.
Key Specifications
| Brand | Texas Instruments Precision Delta-Sigma ADC Series |
|---|---|
| RoHS Status | Lead-free, Halogen-free, RoHS Compliant |
| EDA Files | Schematic symbols, footprint and 3D STEP files available on request |
| Warranty | 1-Year Factory Quality Warranty |
| Package / Case | 48-TQFP (7mm × 7mm × 0.5mm) |
| Mounting Type | SMT Surface Mount Reflow Soldering |
| Surface Marking / Silkscreen | ADS1216Y Marking |
| ADC Architecture | Delta-Sigma, 24-bit no missing codes |
| Effective Resolution | 22 bits (PGA=1), 19 bits (PGA=128) |
| Input Channels | Software selectable: 8 differential / 8 single-ended |
| PGA Gain Options | 1, 2, 4, 8, 16, 32, 64, 128 |
| Max Sampling Rate | 780 SPS (0.78 ksps) |
| Integral Non-Linearity (INL) | ±0.0015% Full Scale (Typical) |
| Internal Reference | 2.5V low drift on-chip voltage reference |
| Sensor Excitation IDAC | 0.5mA / 1mA / 2mA adjustable constant current |
| Analog Input Impedance | Over 100MΩ high impedance buffer input |
| Communication Interface | 4-wire SPI / SSI compatible serial bus |
| On-Chip Storage | Internal RAM for calibration and configuration data |
| Analog Supply Voltage | 2.7V ~ 5.25V |
| Digital Supply Voltage | 2.7V ~ 5.25V |
| Typical Power Consumption | 1mW full operation mode |
| Operating Temperature | -40°C ~ +85°C Industrial Range |
Typical Applications
- Industrial weighing scales, load cell & strain gauge detection
- RTD/thermocouple multi-channel temperature data loggers
- Laboratory precision measuring instruments
- Medical diagnostic testing equipment
- Factory automation remote signal acquisition modules
Order & Shipping Info
| Minimum Order Quantity | 1 Piece |
|---|---|
| Ship Out Time | Shipped within 1-2 business days |
| Global Delivery Time | 3-7 working days |
| Transport Carriers | DHL, UPS, FedEx, EMS |
| Packaging Format | Tape & Reel, 2000 units per reel (suffix /2K) |
| Payment Options | T/T Bank Transfer, PayPal, Credit Card, Western Union |
Technical Support
Contact us via inquiry form for datasheets, samples, bulk price and stock check, reply within 24 hours.
Frequently Asked Questions
Q1: Is ADS1216Y/2K 100% original TI stock?
A: All goods are brand new original TI components, complete batch quality inspection, shipped with factory anti-static tape reel packaging.
Q2: What does suffix /2K stand for?
A: /2K means 2000 pieces per standard tape reel, optimized for automated SMT production lines.
Q3: Why integrated PGA and reference are important for sensors?
A: Weak millivolt sensor signals are amplified internally, built-in reference eliminates external precision components to reduce circuit noise and PCB size.
Q4: Can analog and digital power rails use the same voltage?
A: Yes, both AVDD and DVDD support 2.7V~5.25V supply, you can use unified power rail or separate power supply for better anti-interference performance.
Q5: Can I order small samples before bulk purchase?
A: Sample orders from 1 piece are supported, we can provide short delivery samples for your prototype testing.
Q6: What is the warranty period of this ADC chip?
A: We offer 1-year quality warranty for all ADS1216Y series products against factory defects.
Q7: How fast can you ship out my order after payment?
A: In-stock items will be shipped within 1-2 working days after payment confirmation.
Q8: Is this chip compatible with RTD and strain gauge sensors?
A: Yes, the built-in IDAC excitation current sources perfectly match RTD, thermocouple and load cell signal acquisition.
Q9: What should I do if I need a large bulk quotation?
A: Submit your BOM list via the inquiry form, we will provide competitive bulk pricing within 24 hours.
