BLC9G27LS-151AV
BLC9G27LS-151AV
| Part Number | BLC9G27LS-151AV |
|---|---|
| Manufacturer | Ampleon |
| Category | Discrete Semiconductor Products > Transistors > FETs, MOSFETs > RF MOSFETs / Power Transistors |
| Description | 150W LDMOS Power Transistor, Asymmetric Doherty RF Power Module, 2496MHz to 2690MHz Base Station Power Amplifier, SOT1275-3 Flangeless Package. |
| Stock Status | In Stock |
| Origin | Original Factory |
Product Overview
The BLC9G27LS-151AV is a high-efficiency asymmetric Doherty LDMOS RF transistor from Ampleon, targeted at 2496–2690 MHz cellular base station equipment for LTE and 5G sub-6GHz. This device integrates main & peak transistor paths inside one SOT1275-3 flangeless ceramic package, offering 150W peak power gain. Built-in input/output matching simplifies PCB layout, reduces memory effects and delivers stable thermal performance for RRH and Massive MIMO transmit systems.
Core Advantages
Integrated Asymmetric Doherty Architecture
Integrated main and peak power stages streamline RF layout, realizing high drain efficiency above 45% at 8 dB power back-off.
High Efficiency & Great Linearity
Fully optimized for LTE, LTE-A and 5G NR modulation standards, compatible with DPD linearization and features low memory effects.
Built-in Input & Output Matching
On-chip impedance matching cuts external components, shrinks PCB area and lowers total BOM cost.
Strong Robustness & Thermal Stability
Low thermal-resistance flangeless ceramic housing supports continuous high-power operation and withstands severe antenna load mismatch.
Key Specifications
| Brand | Ampleon |
|---|---|
| RoHS Status | RoHS Compliant / Lead-Free / Green |
| EDA/CAD Resources | Symbol, Footprint & 3D Model Available |
| Warranty | 1-Year Standard Quality Warranty |
| Package / Case | SOT1275-3 Flangeless Ceramic Package |
| Mounting Type | Flangeless Surface Mount / Direct Heat-Sink Mounting |
| Surface Marking / Silkscreen | BLC9G27LS-151AV Marking |
| Transistor Technology | 9th Generation LDMOS (Lateral Diffused MOS) |
| Frequency Range | 2496 MHz to 2690 MHz (Band 7 / Band 38 / Band 41) |
| Peak Output Power (P3dB) | Typ. 150 W (Vds = 28V) |
| Operating Drain Voltage (Vds) | 28 V DC (Nominal); Vds breakdown ≥65V |
| Gate Voltage (Vgs Max) | -5 V |
| Quiescent Drain Current (Idq) | Typ. 280 mA (Main Path) |
| Power Gain (Gp) | Typ. 13.5 dB at f = 2600MHz |
| Doherty Drain Efficiency (ηd) | Typ. 47% or higher at 8 dB power back-off |
| Load Mismatch Tolerance | Survives 10:1 VSWR all-phase mismatch (Vds=28V, PL=50W) |
| Operating Junction Temperature (Tj) | -40°C to +200°C |
| Storage Temperature Range | -65°C ~ +150°C |
| Protection Feature | Integrated Internal ESD Protection |
| Packaging Format | Tray / Anti-Static Packaging |
Typical Applications
- Macro cellular base station RF power amplifiers (LTE, LTE-Advanced, 5G Sub-6GHz)
- Remote Radio Head (RRH) and Remote Radio Unit (RRU) transmitter final stages
- Active Antenna Systems (AAS) and Massive MIMO transceivers (Band 41 / 2.6 GHz)
- Commercial wireless repeaters, microcell boosters
- Broadband sub-3GHz industrial RF transmitter modules
Order & Shipping Info
| Minimum Order Quantity (MOQ) | 1 Piece |
|---|---|
| Processing Lead Time | Shipped within 1-2 business days |
| International Transit Time | 3-7 working days worldwide |
| Available Shipping Methods | DHL, UPS, FedEx, EMS |
| Payment Methods | T/T (Bank Transfer), PayPal, Credit Card, Western Union |
Technical Support
Please use the inquiry form to request official datasheets, sample requests, stock verification, bulk pricing or schematic support. We will reply to your message within 24 hours.
