BQ24610RGER
BQ24610RGER
| Part Number | BQ24610RGER |
|---|---|
| Manufacturer | Texas Instruments |
| Category | Power Management ICs; Multi-Cell Battery Charger Controllers |
| Description | Synchronous Buck Battery Charger Controller, 1-6 Cell Li-Ion/Li-Polymer, High-Efficiency, VQFN-24 Package |
Product Overview
The BQ24610RGER is a high-efficiency synchronous buck battery charger controller designed for 1 to 6 series-cell Li-Ion/Li-Polymer battery packs. It implements a high-performance switching topology for superior efficiency and thermal performance compared to linear chargers, making it suitable for high-power applications. The device supports accurate constant-current (CC) and constant-voltage (CV) charging regulation, input overvoltage protection, battery thermal protection, and programmable charge current and voltage via external resistors. With wide input and output voltage ranges, it provides robust and flexible charging control for industrial, portable, and high-capacity battery systems. Housed in a compact VQFN-24 surface-mount package, it enables high-efficiency, high-power density charging solutions.
| Key Specifications | |
|---|---|
| RoHS Status | RoHS Compliant |
| EDA / CAD Models | 3D Model, Symbol, Footprint Available |
| Warranty | 2-Year Warranty |
| Brand | Texas Instruments |
| Battery Cells | 1 to 6 Series Cells (Li-Ion/Li-Polymer) |
| Topology | Synchronous Buck |
| Control Type | CC/CV Regulation, Programmable |
| Package Type | VQFN-24 |
| Protection Features | OVP, OCP, Thermal Protection, Battery Short Protection |
| Operating Temperature | -40°C to +125°C |
Typical Applications
- 1-6 Cell Li-Ion Battery Packs
- High-Power Portable Devices
- Industrial Battery Systems
- Uninterruptible Power Supplies (UPS)
- Electric Tools and Garden Equipment
- Emergency Lighting Systems
- High-Capacity Power Banks
- Medical Battery Powered Devices
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
