DG409DY-T1-E3
DG409DY-T1-E3
| Part Number | DG409DY-T1-E3 |
| Manufacturer | Vishay |
| Category | Integrated Circuits > Analog Switches > Dual 4-Channel Multiplexer |
| Description | Dual Independent 4-to-1 Analog Multiplexer, CMOS Analog Switch IC,SOIC-16 Package |
Product Overview
The DG409DY-T1-E3 is a high-performance dual 4-channel analog multiplexer manufactured by Vishay with advanced CMOS process technology. It consists of two separate 4-to-1 multiplexers controlled by common address pins and enable signal, featuring low on-resistance, low leakage current and fast switching speed to minimize signal distortion during analog signal routing. Compatible with single supply and dual supply working modes, the device supports wide input signal range close to supply rails. Compact SMD package is suitable for automated SMT assembly, widely applied in data acquisition systems, instrumentation signal switching and industrial analog circuit design.
Key Specifications
| Brand | Vishay |
| RoHS | RoHS Compliant |
| EDA / CAD | Symbols, Footprints, 3D Models Available |
| Warranty | 1 Year Standard Warranty |
| Package / Case | SOIC-16 |
| Mounting Type | Surface Mount |
| Surface Marking / Silkscreen | DG409DY Marking |
| Channel Configuration | Dual 4:1 Multiplexer |
| Supply Voltage Range | 5V ~ 36V Single / ±5V ~ ±20V Dual |
| Typical On Resistance | 100Ω（Max 125Ω） |
| Switching Time | 160ns, 180ns Max |
| Operating Temperature | -40°C ~ 85°C |
Typical Applications
- Multi-Channel Data Acquisition Equipment
- Industrial Instrument Analog Signal Switching
- Multichannel Sensor Signal Select Circuit
- Audio & Test Equipment Signal Routing
- PLC Auxiliary Analog Input Modules
- Battery Powered Portable Measuring Instruments
- IoT Multi-Sensor Collecting Boards
- Automotive Electronic Diagnostic Circuits
