EP4CE115F29C8N
EP4CE115F29C8N
| Part Number | EP4CE115F29C8N |
|---|---|
| Manufacturer | Intel (Formerly Altera) |
| Category | Integrated Circuits (ICs) > Embedded – FPGAs (Field Programmable Gate Array) |
| Description | Cyclone IV E High-Density FPGA, 114,480 Logic Elements, 3,981 Kbits RAM, 266 Multipliers, 528 User I/Os, 780-FBGA Package. |
| Stock Status | In Stock |
| Origin | Original Factory |
Product Overview
The EP4CE115F29C8N is a high-density low-power FPGA belonging to Intel (Altera) Cyclone IV E family. Based on optimized 60nm low-power process, it features 114,480 LEs, ~4 Mbit embedded M9K memory and 266 dedicated 18×18 multipliers. Supporting up to 528 multi-voltage user I/Os and LVDS differential interfaces, this 780-FBGA packaged chip delivers powerful parallel computing for embedded systems, video processing and communication controllers, ideal for industrial automation and high-speed digital signal processing hardware.
Core Advantages
High-Density Logic Capacity
114,480 Logic Elements on a 60nm architecture, sufficient routing and logic resources for complex system-on-chip and custom processor implementations.
Extensive Embedded Memory & Multipliers
Integrated 266 dedicated 18×18 multipliers and 3.98Mbit M9K memory blocks, supporting fast parallel arithmetic, high-bandwidth data buffering and real-time DSP pipelines.
Flexible High-Count User I/O Interface
Up to 528 configurable I/O pins across multi-voltage banks, compatible with 3.3V/2.5V/1.8V/1.5V LVCMOS/LVTTL and high-speed LVDS for multi-chip interconnection.
Comprehensive Development & IP Support
Fully compatible with Intel Quartus Prime software, including synthesis, placement & routing, timing analysis tools and abundant ready-to-use IP cores.
Key Specifications
| Brand | Intel / Altera Cyclone IV E Series |
|---|---|
| Part Number | EP4CE115F29C8N |
| RoHS Status | RoHS Compliant / Lead-Free / Green Package (N Suffix) |
| Process Technology | 60 nm CMOS Technology |
| EDA/CAD Model | Schematic symbol models, 3D CAD step profiles, and 780-FBGA footprint land patterns are available on request |
| Warranty | 1-Year Standard Quality Warranty |
| Package / Case | 780-FBGA (29.00 mm × 29.00 mm, 1.00 mm Pitch) |
| Mounting Type | Surface Mount (SMT / SMD) |
| Surface Marking / Silkscreen | EP4CE115F29C8N (Altera) logo, Marking |
| Logic Elements (LEs) | 114,480 Logic Elements |
| Logic Array Blocks (LABs) | 7,155 LABs |
| Total RAM Bits | 3,981,312 Bits (~3.98 Mbits, 432 M9K Blocks) |
| Embedded Multipliers (18×18) | 266 Dedicated Multipliers |
| Phase-Locked Loops (PLLs) | 4 General-Purpose PLLs |
| Number of User I/Os | Up to 528 Programmable I/O Pins |
| Core Voltage (VCCINT) | 1.15V ~ 1.25V, Typical 1.2V |
| I/O Supply Standards | Supports multiple single-ended and differential I/O voltage standards |
| Speed Grade | Speed Grade 8 |
| Operating Temperature Range | 0°C to +85°C (Commercial Grade Specification) |
Typical Applications
- High-end industrial automation controllers, robotic multi-axis motion controllers, and heavy machinery logic units
- Advanced networking routers, multi-port Ethernet switches, packet inspection gateways, and telecom interface boards
- High-definition broadcast video processing systems, real-time video stream switchers, and image multiplexers
- Medical imaging equipment, high-channel data acquisition systems, and diagnostic testing instrumentation
- University research platforms, high-capacity FPGA development evaluation boards, and hardware prototyping systems
Order & Shipping Info
| Minimum Order Quantity (MOQ) | 1 Piece |
|---|---|
| Shipping Time | Shipped within 1-2 business days |
| Delivery Time | 3-7 working days worldwide |
| Shipping Methods | DHL, UPS, FedEx, EMS |
| Payment Methods | T/T (Bank Transfer), PayPal, Credit Card, Western Union |
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
Frequently Asked Questions
Q1: What do the alphanumeric codes in EP4CE115F29C8N mean?
A: “EP4CE” stands for Cyclone IV E low-power family; “115” means ~115K logic elements; “F29” refers to the 780-ball FBGA package; “C8” is commercial temperature grade (0°C ~ +85°C) with speed grade 8; “N” indicates lead-free RoHS compliant device.
Q2: Which software supports EP4CE115F29C8N design and programming?
A: Intel Quartus Prime (Standard / Pro Edition). Engineers can develop with Verilog HDL / VHDL, complete synthesis, timing analysis and generate configuration bitstreams.
Q3: How to load configuration bitstream on power-up?
A: This SRAM-based FPGA is volatile. It loads firmware from external non-volatile flash (EPCS64 / EPCQ128 etc.) via Active Serial (AS) mode, or programmed through JTAG / Passive Serial (PS) interface.
Q4: What power rails are required for this FPGA?
A: Main supplies: 1.2V core voltage (VCCINT), 2.5V PLL analog supply (VCCA). Bank VCCIO supports 1.2V, 1.5V, 1.8V, 2.5V, 3.3V according to external I/O standards.
Q5: Can you provide free samples of EP4CE115F29C8N for prototype testing?
A: We support sample orders for project verification. Submit your demand via inquiry form including quantity and application information.
Q6: Is there a pin-to-pin compatible alternative for EP4CE115F29C8N?
A: Speed grade variant EP4CE115F29C7N is compatible. Contact us to check stock and timing performance difference.
Q7: Can this commercial grade chip work below 0°C in practical equipment?
A: The official specification range is 0°C~+85°C. Low-temperature operation outside datasheet limits requires full reliability validation by customers.
Q8: What is your typical lead time for bulk orders?
A: In-stock items can be shipped within 1~3 working days. Long lead time orders will be quoted separately after confirmation.
