EP4CE55F23C8N
EP4CE55F23C8N
| Part Number | EP4CE55F23C8N |
|---|---|
| Manufacturer | Intel / Altera |
| Category | Integrated Circuits (ICs) > Embedded – FPGAs (Field Programmable Gate Array) |
| Description | Cyclone IV E FPGA, 55,856 Logic Elements, 2,396 Kbits RAM, 324 User I/Os, 484‑FBGA Package, Commercial Grade. |
| Stock Status | In Stock |
| Origin | Original Factory |
Product Overview
The EP4CE55F23C8N is a low‑cost low‑power Cyclone IV E FPGA from Intel (Altera), built on 60nm CMOS process. It features 55,856 logic elements, 2,396Kbits embedded RAM and 154 DSP multipliers. Housed in 484‑FBGA(23×23mm) package, it supports up to 324 user I/Os and 4 PLLs. Suitable for cost‑sensitive embedded, industrial control and video applications, fully supported by Quartus Prime design software.
Core Advantages
Low‑Cost Low‑Power 60nm Process
Power‑optimized architecture, lowers static and dynamic power for cost‑sensitive equipment.
Rich On‑Chip Memory & DSP Resources
Large M9K RAM blocks and abundant hardware multipliers for data buffering and DSP algorithm processing.
Flexible I/O And Clock Resources
324 configurable I/O pins support multiple I/O standards; 4 PLLs provide stable clock management.
Mature Development Ecosystem
Compatible with Quartus Prime, plenty ready‑to‑use IP cores shorten project development cycle.
Key Specifications
| Brand | Intel / Altera |
|---|---|
| RoHS Status | RoHS Compliant / Lead‑Free (“N” suffix) |
| EDA / CAD | PCB Footprint & 3D Model Available upon Request |
| Warranty | 1‑Year Standard Quality Warranty |
| Package / Case | 484‑FBGA (FineLine BGA, 23mm × 23mm) |
| Mounting Type | Surface Mount Device (SMD/SMT) |
| Moisture Sensitivity Level | MSL‑3 (168 Hours) |
| Surface Marking / Silkscreen | EP4CE55F23C8N Marking |
| FPGA Family | Cyclone IV E |
| Process Technology | 60nm CMOS |
| Number of Logic Elements (LEs) | 55,856 |
| Logic Array Blocks (LABs) | 3491 LABs |
| Total Embedded RAM | 2,396 Kbits (2,396,160 bits) |
| Embedded Multipliers (18×18) | 154 |
| Number of Phase Locked Loops (PLLs) | 4 |
| Number of User I/Os | 324 I/O Pins |
| Core Supply Voltage (Vccint) | 1.2 V Nominal (Allowable:1.15V‑1.25V) |
| Speed Grade | 8 (Commercial) |
| Operating Junction Temperature | 0°C to +85°C (TJ, Commercial Grade) |
Typical Applications
- Industrial Automation, Programmable Logic Controllers (PLCs), and Motor Drives
- Video & Image Processing, Display Bridging, and Security Camera Systems
- Telecommunication Base Stations, Network Routers, and Data Interfaces
- Medical Imaging, Diagnostic Monitoring Equipment, and Ultrasound Devices
- Test & Measurement Instrumentation, Data Acquisition, and Embedded Computing
Order & Shipping Info
| Minimum Order Quantity (MOQ) | 1 Piece |
|---|---|
| Shipping Time | Shipped within 1‑2 business days |
| Delivery Time | 3‑7 working days worldwide |
| Shipping Methods | DHL, UPS, FedEx, EMS |
| Payment Methods | T/T (Bank Transfer), PayPal, Credit Card, Western Union |
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
Frequently Asked Questions
Q1: What do suffixes F23‑C8‑N mean for EP4CE55F23C8N?
A: F23 = 484‑FBGA 23mm package; C = commercial temperature 0~+85℃; 8 = speed grade‑8; N = lead‑free RoHS compliant.
Q2: What is the difference between EP4CE55F23C8N and EP4CE55F23I8N?
A: Pin‑to‑pin compatible. C suffix: commercial grade 0‑85℃. I suffix: industrial grade ‑40~+100℃ junction temperature.
Q3: Can EP4CE55F23C8N directly replace EP4CE40F23C8N?
A: Same 484‑FBGA footprint, pin compatible. EP4CE40 has fewer logic resources. Project recompilation & timing check required, not drop‑in replacement.
Q4: What is the physical package size?
A: 484‑FineLine FBGA, body dimension 23mm × 23mm.
Q5: Which design software supports this FPGA?
A: Intel Quartus Prime, native Cyclone IV‑E device support built‑in.
Q6: Are there other speed‑grade versions in same package?
A: EP4CE55F23C7N(speed‑7), EP4CE55F23C6N(speed‑6). Pin‑compatible, only timing performance differs.
Q7: What is the recommended migration device for new projects?
A: 10CL055YE144C8G (Cyclone‑10 LP). Better power efficiency, different package, PCB redesign required.
Q8: Where can I get datasheet, pin‑map and bulk quotation?
A: Submit inquiry for datasheet, BGA pin‑map, stock status and volume pricing.
