HDL6M05584
HDL6M05584
| Part Number | HDL6M05584 |
|---|---|
| Manufacturer | ABLIC Inc. |
| Category | Integrated Circuits (ICs) > Interface ICs > Specialized High-Voltage Driver |
| Description | 8-channel 3-level RTZ high-speed ultrasound pulser, integrated level shifters, floating voltage regulators, high-current MOSFET drivers and active T/R switch for medical ultrasonic imaging devices. |
| Stock Status | In Stock |
| Origin | Original Factory |
Product Overview
HDL6M05584 is a dedicated ultrasound pulse driver IC from ABLIC. It supports ±100V high voltage output and ±2A peak sink/source current for ultrasound probes. Built with SOI CMOS technology, it features low crosstalk, built-in thermal protection and ESD clamp circuits, widely used in medical B-ultrasound diagnostic equipment.
Core Advantages
8-Channel High Voltage Drive
Supports independent 3-level pulse output up to ±100V, matched to mainstream ultrasonic transducer probes.
Integrated Complete Peripheral Circuit
Onboard MOSFET gate buffers, floating regulators and T/R active switches reduce external BOM quantity and PCB layout area.
Low Noise & Low Crosstalk Design
SOI manufacturing process eliminates latch-up risk, with built-in noise suppression diodes for stable medical-grade signal output.
Comprehensive Protection Mechanism
Over-temperature auto shutdown, power-on reset and ESD protection ensure long-term stable operation of medical equipment.
Key Specifications
| Brand | ABLIC Medical Interface Series |
|---|---|
| RoHS | RoHS Compliant, Lead-Free |
| EDA/CAD Files | Schematic symbols, PCB footprints and 3D models available on request |
| Warranty | 1-Year Quality Warranty |
| Package / Case | QFN-64 (9mm × 9mm) |
| Mounting Type | SMT Surface Mount |
| Surface Marking / Silkscreen | HDL6M05584 Marking |
| Output Voltage Range | 0 ~ ±100V |
| Peak Output Current | ±2A Source & Sink |
| Logic Interface Voltage | 1.8V ~ 5V CMOS Compatible |
| Operating Temperature | 0°C ~ +75°C (Commercial Grade, Non-industrial) |
| Channel Count | 8 Independent Output Channels |
| Process Technology | SOI CMOS Process |
| Inter-channel Crosstalk | Ultra-low crosstalk performance |
| Built-in Protection | OTP thermal shutdown, ESD protection clamp, power-on reset (POR) |
| High Voltage Supply Rail | ±100V dedicated HV power input |
| Digital Supply Rail | 1.8V ~ 5V logic power supply |
| On-chip Integrated Modules | 3-level RTZ level shifter, transmit/receive switch, floating voltage regulator |
Typical Applications
- Medical B-mode Ultrasound Diagnostic Equipment
- Portable Doppler Ultrasonic Scanners
- Multi-channel Ultrasonic Transmit Probe Driver Boards
- Medical Imaging Front-End Signal Processing Modules
Order & Shipping Info
| Minimum Order Quantity (MOQ) | 1 Piece |
|---|---|
| Shipping Time | Shipped within 1-2 business days |
| Delivery Time | 3-7 working days worldwide |
| Shipping Methods | DHL, UPS, FedEx, EMS |
| Payment Methods | T/T (Bank Transfer), PayPal, Credit Card, Western Union |
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
Frequently Asked Questions
Q1: Are HDL6M05584 parts brand-new original ABLIC stock?
A: All in-stock chips are 100% factory original ABLIC goods, stored in anti-static trays and moisture-proof vacuum bags complying with JEDEC storage standards.
Q2: What is the main usage of HDL6M05584?
A: It is an 8-channel high-voltage ultrasound pulser, specially designed to drive ultrasonic probes in medical diagnostic imaging devices.
Q3: Is this chip industrial temperature grade?
A: No, it is commercial grade with standard working temperature range 0°C ~ +75°C, not suitable for high/low temp industrial environments.
Q4: What PCB layout suggestions for this high-voltage driver IC?
A: Separate high-voltage power traces and digital logic grounds, place decoupling capacitors close to power pins, and reserve sufficient copper area for thermal dissipation.
Q5: Can I get CAD PCB footprint files for this model?
A: Yes, schematic libraries and QFN-64 PCB footprints can be sent to you after inquiry submission.
Q6: What’s the shipment lead time for in-stock HDL6M05584?
A: Goods will be dispatched within 1~2 working days, global delivery takes 3-7 working days.
