L3GD20TR
L3GD20TR
| Part Number | L3GD20TR |
|---|---|
| Manufacturer | STMicroelectronics |
| Category | Motion Sensors; 3-Axis Digital Gyroscope |
| Description | 16bit High-Performance 3-Axis MEMS Gyroscope, I2C/SPI Interface, LGA-16 Package, Surface Mount |
Product Overview
The L3GD20TR is a high-stability, low-power 3-axis digital MEMS gyroscope designed for precise angular rate measurement in industrial, consumer, and automotive applications. It features programmable full-scale ranges, low noise performance, embedded interrupt functions, and dual I2C/SPI communication interfaces for flexible system integration. The device offers excellent temperature stability, high shock resistance, and long-term reliability for motion tracking, stabilization, and orientation control. Housed in a compact LGA-16 surface-mount package, it supports seamless integration into space-constrained designs.
| Key Specifications | |
|---|---|
| Brand | STMicroelectronics |
| RoHS Status | RoHS Compliant |
| EDA / CAD Models | 3D Model, Symbol, Footprint Available |
| Warranty | 2-Year Warranty |
| Package / Case | LGA-16 (4x4mm) |
| Mounting Type | Surface Mount (SMD) |
| Axis Configuration | 3-Axis (X, Y, Z) Angular Rate |
| Measurement Range | ±250 / ±500 / ±2000 dps Programmable |
| Interface | I2C / SPI Digital Interface |
| Supply Voltage | 2.4V ~ 3.6V |
| Operating Temperature | -40°C to +85°C |
Typical Applications
- Motion Tracking & Orientation Detection
- Camera & Gimbal Stabilization Systems
- Robotics & Autonomous Platforms
- VR/AR Devices & Gaming Controllers
- Drone Flight Control & Navigation
- Industrial Inertial Measurement
- Wearable Motion Sensors
- Consumer Electronics & Smart Devices
Order & Shipping Info
Minimum Order Quantity (MOQ): 1 Piece
Shipping Time: Shipped within 1-2 business days
Delivery Time: 3-7 working days worldwide
Shipping Methods: DHL, UPS, FedEx, EMS
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
