LTM4644IY#PBF
LTM4644IY#PBF
| Part Number | LTM4644IY#PBF |
|---|---|
| Manufacturer | Analog Devices Inc. (ADI) / Linear Technology |
| Category | Integrated Circuits (ICs) > Power Management ICs > DC-DC Step-Down μModule Power Regulators |
| Product Type | 4 Channel Step-Down Power Module (Buck Regulator) |
| Description | Quad output 4A continuous / 5A peak step-down μModule power regulator, configurable as single 16A, dual 12A/4A, triple or quad independent power rails, 4V~14V main input (2.375V min with external bias), industrial grade 77-ball BGA package. |
| Stock Status | In Stock |
| Origin | Original Factory |
Product Overview
The LTM4644IY#PBF is an industrial 4-channel step-down μModule regulator from ADI (Linear Technology). It accepts 4–14V main input (2.375V min with external bias), integrating controllers, power MOSFETs, inductors and internal thermal diode in one 77-ball BGA (9×15×5.01mm) package. Each rail outputs 4A continuous / 5A peak with ±1.5% DC accuracy; channels can be paralleled for up to 16A total output. Equipped with low ripple, external clock sync and full OVP/OCP/thermal protection, it serves as compact plug-and-play power supply for FPGA, ASIC, DSP and industrial multi-rail hardware.
Core Advantages
Flexible Quad Output Parallelability
Four independent 4A continuous / 5A peak output channels that can be externally paralleled to scale flexibly up to a single 16A continuous output rail.
Ultra-High Density Integrated Module
Combines step-down switching controllers, power MOSFETs, internal inductors and closed-loop compensation networks inside one module, drastically reducing PCB layout footprint and BOM component count.
Excellent Thermal & Wide Industrial Temperature Performance
Thermally optimized 77-ball BGA substrate ensures uniform heat dissipation; fully guaranteed performance across full industrial -40°C ~ +125°C operating temperature window, equipped with built-in temperature sensing diode for real-time thermal monitoring.
Comprehensive Multi-Rail Fault Protection
Native integrated overvoltage protection, cycle-by-cycle overcurrent protection and thermal shutdown cut-off across all four output channels to extend long-term system reliability.
Key Specifications
| Brand | Analog Devices Inc. (ADI) / Linear Technology μModule Power Series |
|---|---|
| RoHS Status | RoHS3 Compliant / Lead-Free / Halogen-Free and Green Eco-Standards Approved |
| EDA/CAD Model | 3D STEP Models, Schematic Symbols, and PCB Layout Footprints available upon request |
| Warranty | 1-Year Standard Quality Warranty |
| Package / Case | 77-BGA (9mm × 15mm × 5.01mm) |
| Mounting Type | Surface Mount Technology (SMD/SMT Ball Reflow Solder) |
| Surface Marking / Silkscreen | LTM4644Y Marking |
| Number of Output Channels | 4 Independent Adjustable Output Rails |
| Input Voltage Scope | 4.0V to 14.0V Main Input Rail range (Scales down to 2.375V when using an external bias supply) |
| Output Voltage Spectrum | 0.6V to 5.5V adjustable independently for each of the four output channels |
| Per Channel Output Current | 4A Continuous Current, 5A Peak Transient Current |
| Max Parallel Combined Current | 16A Total Continuous Output (All 4 Channels Paralleled) |
| DC Output Voltage Accuracy | High-precision total DC output regulation window accuracy |
| Switching Frequency Spectrum | Selectable or programmable frequency control ranging from 300 kHz up to 1.3 MHz |
| External Clock Synchronization | Supports external clock phase-locking sync options to eliminate harmonic beat noise |
| Operating Temperature Range | -40°C to +125°C (Industrial-Grade Full Guaranteed Extended Temperature Operation Limits) |
| Storage Temperature | -40°C ~ +125°C |
| Moisture Sensitivity Level (MSL) | MSL 3 (168 hours, 30°C / 60%RH) |
| Built-in Thermal Diode | Internal Temperature Sensing Diode for Real-Time Thermal Monitoring |
| Protection Functions | OVP, Cycle-by-Cycle OCP, Thermal Shutdown for All Channels |
Typical Applications
- Multi-Rail FPGA, ASIC, DSP, and Microprocessor Core Power Architectures
- High-Density Telecom Infrastructure Routers, Base Station Cards, and Network Switches
- Industrial Control Boards, Advanced Robotic Systems, and Multi-Sensor Processing Equipment
- PCI Express (PCIe) Interface Accel Cards, Enterprise Servers, and Cloud Datacenter Modules
- Medical Imaging Electronics, Automated Test Equipment (ATE), and Precision Airborne Avionics Gauges
Order & Shipping Info
| Minimum Order Quantity (MOQ) | 1 Piece |
|---|---|
| Shipping Time | Shipped within 1-2 business days |
| Delivery Time | 3-7 working days worldwide |
| Shipping Methods | DHL, UPS, FedEx, EMS |
| Payment Methods | T/T (Bank Transfer), PayPal, Credit Card, Western Union |
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
