LV8548MC-AH
LV8548MC-AH
| Part Number | LV8548MC-AH |
|---|---|
| Manufacturer | onsemi (ON Semiconductor) |
| Category | Motor Driver ICs; 2-Channel DC/Stepper Motor Drivers |
| Description | 2-Channel Low Saturation Voltage Motor Driver, 4V–16V, 1A Output, SOIC-10 Package for 12V System Applications |
Product Overview
The LV8548MC-AH is a high-efficiency 2-channel forward/reverse motor driver IC optimized for 12V system products. It features DMOS output transistors with low on-resistance (1Ω typ), supporting a wide supply voltage range of 4V to 16V and a maximum output current of 1A per channel. The device can drive two DC motors, one DC motor via parallel connection, or a stepper motor in full-step and half-step modes. It offers standby mode with zero current consumption, built-in brake function, and parallel channel connection capability. Housed in a compact SOIC-10 surface-mount package, it delivers reliable performance for consumer appliances, office equipment, and industrial motion control systems.
| Key Specifications | |
|---|---|
| RoHS Status | RoHS Compliant (Pb-Free/Halogen Free) |
| EDA / CAD Models | 3D Model, Symbol, Footprint Available |
| Warranty | 2-Year Warranty |
| Brand | onsemi (ON Semiconductor) |
| Driver Type | 2-Channel Half-Bridge Motor Driver |
| Supply Voltage | 4.0V ~ 16.0V (VCC Max: 20V) |
| Output Current | 1A Per Channel (Max) |
| On-Resistance (RON) | 1Ω (Typical, Upper + Lower) |
| Package Type | SOIC-10 (Surface Mount) |
| Operating Temperature | -30°C to +85°C |
Typical Applications
- Refrigerator & Home Appliance Motor Control
- Flatbed/Document Scanners & Office Equipment
- POS Printers, Label Printers & PoE Terminals
- Clothes Dryers, Vacuum Cleaners & Small Household Devices
- Time Recorders & Access Control Systems
- DC Motor & Stepper Motor Drive Applications
- 12V System Industrial & Consumer Electronics
- Battery-Powered Motion Control Devices
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
