MC14060BDR2G
MC14060BDR2G
| Part Number | MC14060BDR2G |
|---|---|
| Manufacturer | ON Semiconductor |
| Category | Logic ICs; 14-Stage Ripple-Carry Binary Counter/Divider |
| Description | 14-Stage Ripple-Carry Binary Counter with Oscillator, 3V-18V, SOIC-16 Surface Mount Package |
Product Overview
The MC14060BDR2G is a 14-stage ripple-carry binary counter/divider with an integrated oscillator circuit, designed for general-purpose timing, frequency division, and counting applications. It operates over a wide supply voltage range of 3V to 18V, features a built-in crystal/RC oscillator, master reset function, and low power consumption. The device provides 14 binary counter stages with high noise immunity and stable CMOS performance, ideal for long-duration timing, clock generation, and frequency division in industrial, consumer, and automotive electronics. Housed in a compact SOIC-16 surface-mount package, it supports high-density PCB design and reliable SMT assembly.
| Key Specifications | |
|---|---|
| RoHS Status | RoHS Compliant |
| EDA / CAD Models | 3D Model, Symbol, Footprint Available |
| Warranty | 2-Year Warranty |
| Brand | ON Semiconductor |
| Counter Stages | 14-Stage Ripple-Carry Binary |
| Oscillator | Built-in Crystal / RC Oscillator |
| Supply Voltage | 3.0V ~ 18.0V |
| Package Type | SOIC-16 (Surface Mount) |
| Operating Temperature | -55°C to +125°C |
Typical Applications
- Long-Duration Timing & Delay Circuits
- Frequency Division & Clock Generation
- Digital Counting & Event Detection
- Industrial Timers & Control Systems
- Consumer Electronics & Appliances
- Automotive Timing Modules
- Low-Power Oscillator & Counter Systems
- Embedded System Clock Dividers
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
