MC14504BDR2G
MC14504BDR2G
| Part Number | MC14504BDR2G |
|---|---|
| Manufacturer | ON Semiconductor |
| Category | Logic Level Translators; Hex Voltage Level Shifters |
| Description | Hex Non-Inverting Voltage Level Translator, 3V to 18V Operation, Bi-Directional Compatible, SOIC-16 Package |
Product Overview
The MC14504BDR2G is a hex non-inverting CMOS voltage level translator designed for bidirectional logic level conversion between different voltage domains. It supports a wide operating voltage range from 3V up to 18V, enabling seamless signal translation between low-voltage logic (such as 3.3V/5V) and higher-voltage CMOS systems. The device features six independent translation channels, high input impedance, low quiescent current, and robust noise immunity for reliable operation in mixed-voltage industrial and embedded systems. With its non-inverting architecture and wide compatibility, it simplifies system design for multi-voltage interfaces. Housed in a standard SOIC-16 surface-mount package, it supports high-density PCB assembly and automated manufacturing.
| Key Specifications | |
|---|---|
| RoHS Status | RoHS Compliant |
| EDA / CAD Models | 3D Model, Symbol, Footprint Available |
| Warranty | 2-Year Warranty |
| Brand | ON Semiconductor |
| Channels | 6 Independent Non-Inverting Channels |
| Supply Voltage | 3V ~ 18V |
| Logic Type | CMOS Level Translator |
| Package Type | SOIC-16 |
| Operating Temperature | -40°C to +125°C |
Typical Applications
- Multi-Voltage Logic Level Conversion
- 3.3V to 5V / 12V / 18V Signal Translation
- MCU to High-Voltage Peripheral Interface
- Industrial Control Mixed-Voltage Systems
- Automotive Electronics Signal Buffering
- Consumer Electronics I/O Level Shifting
- General-Purpose CMOS Logic Translation
- Embedded System Multi-Domain Interfaces
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
