MC74HC02ADR2G
MC74HC02ADR2G
| Part Number | MC74HC02ADR2G |
|---|---|
| Manufacturer | ON Semiconductor |
| Category | Logic ICs; Quad 2-Input NOR Gates |
| Description | Quad 2-Input NOR Gate, High-Speed CMOS Logic, 2V-6V, SOIC-14 Package |
Product Overview
The MC74HC02ADR2G is a high-speed, silicon-gate CMOS quad 2-input NOR gate that utilizes advanced silicon-gate CMOS technology to achieve operating speeds similar to low-power Schottky TTL while maintaining CMOS low power dissipation. This device contains four independent 2-input NOR gates and operates over a wide 2.0V to 6.0V supply voltage range, making it compatible with both CMOS and TTL logic interfaces. It features high noise immunity, low input current, and balanced propagation delays, suitable for general-purpose digital logic applications in consumer, industrial, and automotive electronics. Housed in a compact SOIC-14 surface-mount package, it offers reliable performance and easy integration into modern PCB designs.
| Key Specifications | |
|---|---|
| RoHS Status | RoHS Compliant |
| EDA / CAD Models | 3D Model, Symbol, Footprint Available |
| Warranty | 2-Year Warranty |
| Brand | ON Semiconductor |
| Logic Type | Quad 2-Input NOR Gate |
| Supply Voltage | 2.0V ~ 6.0V |
| Logic Family | HC CMOS |
| Package Type | SOIC-14 |
| Operating Temperature | -55°C to +125°C |
Typical Applications
- General-Purpose Digital Logic Circuits
- Industrial Control Systems
- Automotive Electronics
- Consumer Electronics & Appliances
- Embedded System Logic Interfaces
- Computer Peripheral & I/O Circuits
- Signal Conditioning & Logic Conversion
- High-Speed CMOS Logic Designs
