MP2162GQH-Z
MP2162GQH-Z
| Part Number | MP2162GQH-Z |
|---|---|
| Manufacturer | Monolithic Power Systems (MPS) |
| Category | DC-DC Switching Regulators; Synchronous Step-Down Buck Converters |
| Description | 18V Input 2A Synchronous Buck Converter, Ultra-Small, High Efficiency, QFN-8 Package |
Product Overview
The MP2162GQH-Z is a high-efficiency, fully synchronous step-down buck converter designed for compact, low-power portable and embedded systems. It operates from a wide 2.5V to 18V input voltage range and delivers up to 2A continuous output current with excellent load and line regulation. The device features internal power MOSFETs, current-mode control for fast transient response, and pulse-frequency modulation (PFM) to maximize light-load efficiency. Comprehensive protection features include over-current protection (OCP), over-voltage protection (OVP), over-temperature protection (OTP), and under-voltage lockout (UVLO). Housed in an ultra-compact QFN-8 package, it enables high-density PCB design for space-constrained applications.
| Key Specifications | |
|---|---|
| RoHS Status | RoHS Compliant |
| EDA / CAD Models | 3D Model, Symbol, Footprint Available |
| Warranty | 2-Year Warranty |
| Brand | MPS (Monolithic Power Systems) |
| Input Voltage | 2.5V ~ 18V |
| Output Current | 2A Continuous |
| Topology | Synchronous Step-Down Buck |
| Package Type | QFN-8 |
| Operating Temperature | -40°C to +125°C |
Typical Applications
- Portable & Battery-Powered Devices
- IoT Sensors & Wearable Electronics
- MCU/SoC Core Power Supplies
- Industrial Control & Monitoring Modules
- Consumer Electronics & Smart Devices
- Compact DC-DC Power Modules
- LED Lighting & Low-Power Appliances
- High-Density Embedded Systems
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
