MT9F002I12-N4000-DP1
MT9F002I12-N4000-DP1
| Part Number | MT9F002I12-N4000-DP1 |
|---|---|
| Manufacturer | onsemi (Aptina) |
| Category | Sensors, Transducers > Image Sensors, Camera Modules |
| Description | 1/2.3″ 14 MP High‑Speed Digital Color CMOS Image Sensor, A‑Pix™ Pixel Technology, HiSPi/MIPI Output, ILCC‑48 Package, 12° CRA, Manufacturer EOL. |
| Stock Status | In Stock |
| Origin | Original Factory |
Product Overview
MT9F002I12‑N4000‑DP1 is a 1/2.3‑inch 14MP CMOS image sensor by onsemi(Aptina). Adopting A‑Pix™ pixel technology, it achieves low crosstalk and excellent low‑light performance. It supports [email protected], 1080p@60fps, 720p@120fps, with HiSPi, MIPI CSI‑2 and parallel interfaces. ILCC‑48 package, 12° CRA. This device is EOL, only stock available.
Core Advantages
A‑Pix™ Pixel Technology
Optimized pixel structure improves sensitivity and suppresses crosstalk and low‑light noise.
14MP Multi‑Rate Video Output
Supports high‑resolution still capture and high‑speed video for multiple scene requirements.
Multiple High‑Speed Interfaces
HiSPi / MIPI CSI‑2 / parallel interfaces, low EMI, simplify host hardware design.
Flexible On‑Chip Readout
Built‑in binning, windowing and sub‑sampling for flexible resolution switching.
Key Specifications
| Brand | onsemi / Aptina |
|---|---|
| RoHS Status | RoHS Compliant / Lead‑Free |
| EDA / CAD | PCB Footprint & 3D Model Available upon Request |
| Warranty | 1‑Year Standard Quality Warranty |
| Package / Case | ILCC‑48 Package |
| Mounting Type | Surface Mount SMD |
| Surface Marking / Silkscreen | MT9F002I12 |
| Active Array Size | 4608 (H) x 3288 (V) approx. 14.0 Megapixels |
| Optical Format | Type 1/2.3 inch (Diagonal 7.82 mm) |
| Pixel Size | 1.4 µm (H) x 1.4 µm (V) |
| Chroma | Color (RGB Bayer Pattern) |
| CRA (Chief Ray Angle) | 12 ° |
| Maximum Frame Rate | 13.7 fps @ Full 14 MP, 60 fps @ 1080p, 120 fps @720p |
| Output Interface | HiSPi / MIPI CSI‑2 / Parallel Output |
| ADC Resolution | 12‑bit On‑Chip A/D Converter |
| Operating Temperature Range | -30°C to +70°C |
| Product Lifecycle Status | Manufacturer Obsolete / EOL |
Typical Applications
- High‑Resolution Digital Still Cameras (DSC) and Digital Video Camcorders (DVC)
- Industrial Machine Vision, High‑Speed Quality Inspection, and Optical Scanners
- Medical Imaging Systems, Endoscopes, and Microscopy Equipment
- Aerial Mapping, Drones, and Action Sport Cameras
- High‑End Surveillance, Intelligent Traffic Systems (ITS), and AI Edge Vision Devices
Order & Shipping Info
| Minimum Order Quantity (MOQ) | 1 Piece |
|---|---|
| Shipping Time | Shipped within 1‑2 business days |
| Delivery Time | 3‑7 working days worldwide |
| Shipping Methods | DHL, UPS, FedEx, EMS |
| Payment Methods | T/T (Bank Transfer), PayPal, Credit Card, Western Union |
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
Frequently Asked Questions
Q1: What are key specs for MT9F002I12‑N4000‑DP1?
A1: 1/2.3‑inch 14MP CMOS sensor, 4608×3288, 1.4μm pixel, ILCC‑48 package, 12° CRA, EOL status.
Q2: What interfaces does MT9F002I12‑N4000‑DP1 support?
A2: HiSPi, MIPI CSI‑2 and parallel output, compatible with various ISP chips.
Q3: What is the difference between DP and DP1 suffix?
A3: Same die and pinout. ‑DP is tray packing; ‑DP1 is tape‑and‑reel. Direct pin‑to‑pin interchangeable.
Q4: Difference between MT9F002I12‑N4000‑DP1 and MT9F002I12STCV‑DP?
A4: STCV‑DP is 0° CRA. Pin‑compatible, but optical angle and factory tuning differ. Not direct drop‑in replacement; lens and registers need re‑configuration.
Q5: What do‑GEVK and‑GEVB suffix mean?
A5: ‑GEVK = demo kit, ‑GEVB = sensor head board. Neither are standalone sensor chips, only for development.
Q6: Can MT9F002I12‑N4000‑DP1 be used for new projects?
A6: EOL obsolete part, stock only. Not recommended for new designs, select alternative 14MP sensors.
Q7: Can I replace MT9F002 with other‑brand 14MP sensors?
A7: No universal drop‑in substitute. Verify pixel size, CRA, interface, footprint and temperature range before replacement.
Q8: How to get datasheet and bulk price?
A8: Submit inquiry form for datasheet, hardware support, sample and volume quotation.
