NCE07TD60BK
NCE07TD60BK
| Part Number | NCE07TD60BK |
|---|---|
| Manufacturer | NCE Power Semiconductor |
| Category | Power IGBT Transistor |
| Description | 600V 70A IGBT with Anti-Parallel Diode, TO-252 Package, Through Hole Mounting |
Product Overview
The NCE07TD60BK is a high-performance, high-current insulated-gate bipolar transistor (IGBT) designed for high-efficiency power switching applications. It combines low saturation voltage, fast switching speed, and high surge current capability to deliver reliable performance in demanding power control systems. The device integrates a built-in fast recovery anti-parallel diode for freewheeling protection, with excellent thermal stability and ruggedness. Housed in a standard TO-252 through-hole package, it provides superior heat dissipation and easy assembly for industrial power systems.
| Key Specifications | |
|---|---|
| Brand | NCE Power Semiconductor |
| RoHS Status | RoHS Compliant |
| EDA / CAD Models | 3D Model, Symbol, Footprint Available |
| Warranty | 2-Year Warranty |
| Package / Case | TO-252 |
| Mounting Type | Through Hole |
| Vceo Collector-Emitter Voltage | 600 V |
| Ic Continuous Collector Current | 70 A |
| Internal Diode | Fast Recovery Anti-Parallel Diode |
| Operating Temperature | -55°C to +150°C |
Typical Applications
- Switching Power Supplies & Inverters
- Industrial Motor Drives & Controls
- Uninterruptible Power Supplies (UPS)
- Solar Inverters & Renewable Energy Systems
- Welding Machines & Power Converters
- High-Power LED Drivers & Lighting Systems
- Home Appliance Power Control Modules
- Electric Vehicle (EV) Auxiliary Systems
Order & Shipping Info
Minimum Order Quantity (MOQ): 1 Piece
Shipping Time: Shipped within 1-2 business days
Delivery Time: 3-7 working days worldwide
Shipping Methods: DHL, UPS, FedEx, EMS
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
