NCP5106BDR2G
NCP5106BDR2G
| Part Number | NCP5106BDR2G |
|---|---|
| Manufacturer | ON Semiconductor |
| Category | Power Management ICs; High-Speed MOSFET Drivers |
| Description | High-Speed Dual IGBT MOSFET Driver, 4A Peak Current, Half-Bridge Configuration, SOP-8 Package |
Product Overview
The NCP5106BDR2G is a high-speed, high-performance dual MOSFET driver designed for driving N-channel power MOSFETs in half-bridge and full-bridge topologies. It delivers a peak output current of up to 4A, features ultra-fast rise and fall times, and supports a wide operating voltage range for high-efficiency power conversion systems. The device includes under-voltage lockout (UVLO) protection, matched propagation delays, and cross-conduction prevention logic to ensure safe and reliable operation in switching power supplies, motor drives, and DC-DC converters. With its compact SOP-8 surface-mount package, it offers excellent thermal performance and easy integration into high-density power designs.
| Key Specifications | |
|---|---|
| RoHS Status | RoHS Compliant |
| EDA / CAD Models | 3D Model, Symbol, Footprint Available |
| Warranty | 2-Year Warranty |
| Brand | ON Semiconductor |
| Peak Output Current | 4A |
| Driver Configuration | Dual Half-Bridge |
| Package Type | SOP-8 |
| Operating Temperature | -40°C to +125°C |
Typical Applications
- Switching Mode Power Supplies (SMPS)
- DC-DC Converters & Inverters
- Motor Drive & Control Systems
- Class D Audio Amplifiers
- UPS & Industrial Power Systems
- Solar Inverters & Energy Storage
- High-Frequency Power Conversion
- Half-Bridge / Full-Bridge Driver Circuits
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
