PEX8748-BA80BCG
PEX8748-BA80BCG
| Part Number | PEX8748-BA80BCG |
|---|---|
| Manufacturer | Broadcom (Former PLX Technology) |
| Category | Integrated Circuits (ICs) > Interface – Specialized |
| Description | 48-Lane, 12-Port PCI Express Gen 3 (8.0 GT/s) Switch IC with Multi-Host and Non-Transparent Bridge (NTB) capability. |
Product Overview
The PEX8748-BA80BCG is a high-performance 48-lane, 12-port PCI Express Gen 3 ExpressLane™ switch IC developed by Broadcom (formerly PLX Technology). Optimized for high-density multi-host systems, high-end storage arrays and GPU clusters, this device delivers ultra-low latency and a maximum data rate of 8.0 GT/s per lane. Equipped with built-in Non-Transparent Bridging (NTB) and multi-host functions, it enables stable communication between multiple root complexes without performance bottlenecks. Featuring comprehensive on-chip diagnostic tools and advanced low-power design, PEX8748-BA80BCG is an ideal core component for cloud data centers, high-performance computing (HPC) and AI server systems.
Core Advantages
Ultra-High Performance & Bandwidth
Featuring 48 PCIe lanes compliant with Gen 3 standard and 8.0 GT/s per lane transfer speed, this switch provides powerful parallel throughput. It perfectly supports connection for multiple high-speed NVMe storage devices and high-performance accelerator clusters to eliminate transmission bottlenecks.
Flexible Multi-Host and NTB Subsystems
Integrated hardware-based Non-Transparent Bridging (NTB) supports dual-host failover, distributed computing and multi-host cluster deployment, effectively improving system redundancy and overall computing scheduling capability.
Advanced ExpressLane™ Diagnostics
Built-in real-time performance monitoring, signal integrity testing, loopback and error detection functions simplify hardware debugging and system verification, greatly reducing testing and maintenance costs.
Highly Efficient Thermal and Power Design
Dynamic power management automatically disables idle ports and lanes to reduce power consumption and heat generation. It runs stably in densely deployed server racks and meets long-term continuous operation requirements.
Key Specifications
| Brand | Broadcom (Former PLX Technology) |
|---|---|
| RoHS Status | RoHS Compliant / Lead-Free |
| EDA/CAD Model | 3D Model & PCB Footprint Available upon request |
| Warranty | 1-Year Standard Factory Warranty |
| Package / Case | FCBGA-676, 27×27mm |
| Mounting Type | Surface Mount (SMD/SMT) |
| Surface Marking / Silkscreen | PEX8748-BA80BCG |
| PCIe Generation | PCI Express Gen 3 (Backwards compatible with Gen 2 / Gen 1) |
| Total Lane Count | 48 Lanes |
| Total Port Configuration | 12 Ports |
| Data Transfer Rate | 8.0 GT/s per lane |
| Operating Temperature Range | 0°C to +70°C (Commercial / Datacenter Server Grade) |
Typical Applications
- AI Deep Learning Servers and Enterprise GPU Clustering
- High-Density NVMe Storage Arrays and SAN/NAS Storage Systems
- Cloud Data Center Infrastructure and Multi-Host Blade Servers
- High-End Test Equipment and Professional Video Transmission Switches
- High-Performance Network Routers and Communication Equipment
Order & Shipping Info
| Minimum Order Quantity (MOQ) | 1 Piece |
|---|---|
| Shipping Time | Shipped within 1-2 business days |
| Delivery Time | 3-7 working days worldwide |
| Shipping Methods | DHL, UPS, FedEx, EMS |
| Payment Methods | T/T (Bank Transfer), PayPal, Credit Card, Western Union |
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
