RTL8364NBI-CG
RTL8364NBI-CG
| Part Number | RTL8364NBI-CG |
|---|---|
| Manufacturer | Realtek Semiconductor |
| Category | Integrated Circuits (ICs) > Interface > Network Controllers & Ethernet Switches |
| Description | Layer 2 Gigabit Ethernet Switch Controller, 2‑Integrated PHY + 2‑Extended MAC (2+2 Architecture), QFN‑88‑EP Package for industrial network equipment. |
| Stock Status | In Stock |
| Origin | Original Factory |
Product Overview
RTL8364NBI‑CG is Realtek industrial‑grade Layer‑2 Gigabit Ethernet switch controller adopting 2+2 architecture: 2 integrated Gigabit PHY ports plus 2 extended MAC interfaces. It supports non‑blocking wire‑speed forwarding, VLAN, QoS and EEE energy‑saving features. Housed in QFN‑88‑EP (10×10 mm) package, it fits compact industrial terminals, mini‑switches and router expansion modules.
Core Advantages
2+2 Port Mixed Architecture
2 native PHY for direct RJ45 connection; 2 extended MAC for external PHY, CPU or fiber modules, optimizing BOM for compact hardware.
Flexible Interface & Configuration
Supports RGMII/SGMII/MII/RMII/GMII; configurable via I2C‑like, SPI or MIIM management interfaces.
Complete L2 Switch & QoS
Non‑blocking forwarding with 2048‑entry MAC table; port‑priority multi‑queue scheduling for stable industrial real‑time traffic.
Industrial‑Grade Low‑Power
-40℃~+85℃ wide temperature range; IEEE 802.3az EEE power‑saving for light‑load operation.
Key Specifications
| Brand | Realtek Semiconductor |
|---|---|
| RoHS Status | RoHS Compliant / Green (Lead‑Free) |
| EDA / CAD | PCB Footprint & 3D Model Available upon Request |
| Warranty | 1‑Year Standard Quality Warranty |
| Package / Case | QFN‑88‑EP (10×10 mm) |
| Mounting Type | Surface Mount (SMT) |
| Surface Marking / Silkscreen | RTL8364NBI Marking |
| Port Architecture | 2‑Port Integrated Gigabit PHY + 2‑Port Extended MAC (2+2) |
| Data Rate | 10/100/1000 Mbps (10Base‑T / 100Base‑TX / 1000Base‑T) |
| Extension Interfaces | RGMII / SGMII / MII / RMII / GMII |
| Management Interface | I2C‑like, SPI, MIIM |
| Networking Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1Q VLAN, IEEE 802.3az EEE |
| MAC Address Table | Up to 2048 MAC Address Entries |
| Power Supply Voltage | 1.0V‑1.2V Core / 3.3V I/O Supply |
| Operating Temperature Range | ‑40°C to +85°C (Industrial Grade) |
Typical Applications
- 2+2 port compact Gigabit Ethernet switches
- Router and gateway expansion network modules
- Industrial Ethernet equipment, automation control terminals
- IoT edge gateway and embedded network system
- Small‑size smart security and video transmission hardware
Order & Shipping Info
| Minimum Order Quantity (MOQ) | 1 Piece |
|---|---|
| Shipping Time | Shipped within 1‑2 business days |
| Delivery Time | 3‑7 working days worldwide |
| Shipping Methods | DHL, UPS, FedEx, EMS |
| Payment Methods | T/T (Bank Transfer), PayPal, Credit Card, Western Union |
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
Frequently Asked Questions
Q1: What is the main function of RTL8364NBI‑CG?
A: RTL8364NBI‑CG is a Layer‑2 Gigabit Ethernet switch controller. It features 2 integrated PHY plus 2 extended MAC ports for non‑blocking wire‑speed forwarding in embedded and industrial network hardware.
Q2: What interfaces does RTL8364NBI‑CG support?
A: Extended MAC supports RGMII, SGMII, MII, RMII, GMII. Chip configuration is available via I2C‑like, SPI or MIIM management bus.
Q3: What is the difference between suffix NB‑CG and NBI‑CG?
A: RTL8364NB‑CG is commercial grade (0‑70℃). RTL8364NBI‑CG is industrial grade (-40℃~+85℃). They share identical pinout and package. Do not direct drop‑in replacement without full validation under extreme temperature.
Q4: Can RTL8364NBI‑CG work as a 4‑port all‑PHY switch?
A: No. Only 2 ports have built‑in PHY. The other two MAC ports require external PHY or host MAC, cannot drive RJ45 directly.
Q5: Are there pin‑compatible alternative parts?
A: RTL8364NB‑CG is pin‑to‑pin compatible but commercial temperature only. No cross‑brand fully pin‑compatible equivalent. Register and firmware modification will be needed if switching to other vendors.
Q6: How does RTL8364NBI‑CG compare with RTL8367 series?
A: RTL8364NBI‑CG (QFN‑88,2+2 port) targets compact cost‑sensitive devices. RTL8367 series offer more integrated PHY ports, larger MAC table, bigger package and higher cost for multi‑port switch products.
Q7: Does RTL8364NBI‑CG support energy‑saving function?
A: Yes, it supports IEEE 802.3az EEE, dynamic power adjustment based on link and cable conditions.
Q8: How can I get datasheet, reference schematic or bulk quotation?
A: Please submit our inquiry form for datasheet, reference design, stock check and volume pricing support.
