S29GL256N10TFI01
S29GL256N10TFI01
| Part Number | S29GL256N10TFI01 |
|---|---|
| Manufacturer | Infineon Technologies (formerly Cypress Semiconductor / Spansion) |
| Category | Integrated Circuits (ICs) > Memory > NOR Flash |
| Description | 256 Megabit (32M x 8-Bit / 16M x 16-Bit) MirrorBit® 3.0V GL Parallel NOR Flash Memory, 100ns Access Time, Industrial Temperature Range, 56-Pin TSOP Package. |
| Stock Status | In Stock |
| Origin | Original Factory |
Product Overview
The S29GL256N10TFI01 is a 256Mbit parallel NOR Flash adopting MirrorBit dual-bit storage technology, configurable in 8/16-bit bus with 100ns access speed. It runs on 2.7–3.6V Vcc and supports adjustable VIO interface voltage. Packaged in 56-pin TSOP with industrial temperature rating, it fits telecom, industrial control, automotive and high-reliability embedded equipment.
Core Advantages
Advanced MirrorBit® Dual-Bit Technology
Dual-bit storage improves density and cost efficiency while maintaining stable durability.
Flexible Low-Voltage Digital Interfacing
Independent VIO pin matches 1.65V~Vcc logic voltage, eliminating extra level shifters.
High-Efficiency Page-Mode Read Access
8-word page buffer delivers 25ns fast page read to boost boot and XIP performance.
Advanced Hardware Security Options
Lockable ASP register and dedicated silicon sector protect boot firmware and confidential data.
Key Specifications
| Brand | Infineon / Cypress / Spansion Parallel NOR Flash Series |
|---|---|
| RoHS Status | RoHS Compliant / Lead-Free / Halogen-Free Materials |
| EDA/CAD Model | Schematic symbol library, PCB footprint, and 3D modeling tools |
| Warranty | 1-Year Standard Quality Warranty |
| Package / Case | 56-TSOP (14 mm × 20 mm) |
| Mounting Type | Surface Mount |
| Surface Marking / Silkscreen | S29GL256N10TFI01 Marking |
| Memory Size | 256 Mbit (32 Megabytes) |
| Bus Configuration | Configurable 32M x 8-Bit (Byte Mode) or 16M x 16-Bit (Word Mode) via the BYTE# Pin |
| Speed / Random Access Time | 100 ns Maximum Access Time |
| Page Read Access Speed | 25 ns Page Access Speed (8-Word/16-Byte Page Mode) |
| Operating Voltage (Vcc) | 2.7V to 3.6V (Single Power Supply Range) |
| Interface Voltage (VIO) | 1.65V to Vcc Digital I/O Rail Support |
| Program/Erase Endurance | Minimum 100,000 Write/Erase Cycles Per Sector |
| Data Retention | 20 Years Minimum under typical industrial conditions |
| Operating Temperature Range | -40°C to +85°C (Industrial Temperature Grade) |
| Storage Temperature | -40°C ~ +85°C |
| Charge-Discharge Cycle Life | 100,000 times |
| Weight | 1.2g |
| Rated Surge Voltage | 6.3V |
| Internal Resistance (ESR) | Max 120mΩ |
Typical Applications
- Telecommunication Network Equipment, Enterprise Routers, Switches, and Fiber Optic Transceiver Hubs
- Industrial Control Units (PLCs), CNC Smart Machines, and Energy Management Hardware
- Automotive Dashboard Instrumentation, In-Vehicle Infotainment (IVI), and Navigation Controllers
- High-End Embedded Compute Blades, Server Baseboard Management Controllers (BMCs), and RAID Cards
- Medical Imaging Systems, Health Monitoring Equipment, and Secure Transaction Terminals
Order & Shipping Info
| Minimum Order Quantity (MOQ) | 1 Piece |
|---|---|
| Shipping Time | Shipped within 1-2 business days |
| Delivery Time | 3-7 working days worldwide |
| Shipping Methods | DHL, UPS, FedEx, EMS |
| Payment Methods | T/T (Bank Transfer), PayPal, Credit Card, Western Union |
Technical Support
Submit requests for datasheets, samples, stock status and bulk quotations through the inquiry form; we will reply within 24 hours.
Frequently Asked Questions
Q1: How to switch 8-bit and 16-bit bus modes?
A: Control by BYTE# pin. Low = 8-bit mode, High = 16-bit mode.
Q2: What’s the advantage of MirrorBit technology?
A: It stores two bits per cell to raise density without losing data retention.
Q3: Why is independent VIO rail designed?
A: Matches CPU low I/O voltage, removes extra level translation chips.
Q4: What’s the function of Secured Silicon Sector?
A: Store encryption keys and unique IDs, can be permanently locked.
Q5: Is this flash industrial temperature grade?
A: Yes, operating range covers -40°C to +85°C for industrial equipment.
Q6: How many program/erase cycles does it support?
A: Minimum 100,000 write and erase cycles per sector.
Q7: How long can data be stored without power?
A: Up to 20 years of reliable data retention under normal working conditions.
Q8: Is the chip compatible with SMT reflow soldering?
A: Yes, 56-pin TSOP package supports standard SMT reflow process.
