SAK-XC2365B-40F80LR AB
SAK-XC2365B-40F80LR AB
| Part Number | SAK-XC2365B-40F80LR AB |
|---|---|
| Manufacturer | Infineon Technologies |
| Category | Integrated Circuits (ICs) > Embedded – Microcontrollers (MCU) |
| Description | 16/32-Bit C166SV2 Real‑Time Automotive Microcontroller, 80 MHz, 320 KB Flash, 34 KB SRAM, Multi‑CAN, LQFP‑100 Package, EOL Obsolete Device. |
| Stock Status | In Stock |
| Origin | Original Factory |
Product Overview
The SAK‑XC2365B‑40F80LR AB is Infineon XC2000‑series 16/32‑bit automotive‑grade MCU based on C166SV2 core up to 80 MHz. It integrates 320 KB Flash, 34 KB SRAM, 16‑channel 10‑bit ADC and MultiCAN / USIC peripherals. Packaged in PG‑LQFP‑100‑8 (14×14 mm), AEC‑Q100 qualified. Note: Officially End‑of‑Life, not suggested for new‑design projects.
Core Advantages
High‑Speed C166SV2 Core
80 MHz 16/32‑bit core with DSP MAC unit, fast interrupt response for real‑time control applications.
Rich Automotive Communication Interfaces
3‑channel CAN2.0B, USIC supports UART, SPI, I2C, LIN, I2S, meets various vehicle‑bus requirements.
Multi‑Channel 10‑bit ADC
Dual ADC modules with total 16 analog input channels for multi‑sensor signal acquisition.
AEC‑Q100 Automotive‑Grade Robustness
-40℃~+125℃ operating range, integrated watchdog and Data‑Flash EEPROM‑simulation for high‑reliability systems.
Key Specifications
| Brand | Infineon Technologies |
|---|---|
| RoHS Status | RoHS3 Compliant / Halogen‑Free / AEC‑Q100 Qualified |
| EDA / CAD | PCB Footprint & 3D Model Available upon Request |
| Warranty | 1‑Year Standard Quality Warranty |
| Package / Case | LQFP‑100 / PG‑LQFP‑100 (14×14 mm) |
| Mounting Type | Surface Mount Device (SMD/SMT) |
| Packaging Format | Tape & Reel |
| Surface Marking / Silkscreen | SAK-XC2365B-40F80LR AB |
| Core Architecture | 16/32‑Bit C166SV2 Core |
| Maximum CPU Frequency | 80 MHz |
| Program Memory Size | 320 KB Flash |
| RAM Size | 34 KB On‑Chip SRAM |
| I/O Pins Count | 76 Digital I/O Pins |
| Connectivity | MultiCAN (CAN 2.0B), USIC (UART, SPI, I2C, LIN, I2S) |
| A/D Converters | Up to 16 Channels, 10‑bit ADC |
| MSL Level | MSL‑3 (168 Hours) |
| Operating Supply Voltage | 3.0 V to 5.5 V (Single Voltage Supply) |
| Operating Temperature | -40°C to +125°C (Automotive Grade) |
| Lifecycle Status | End‑of‑Life / Obsolete (Not Recommended for New Designs) |
Typical Applications
- Automotive Body Control Units (BCM), Gateway Modules, and Lighting Controls
- Automotive Safety‑Related Auxiliary Control Modules
- Electric Vehicle Auxiliary Inverters, DC/DC Converters, and HVAC Units
- Industrial Motor Control, AC Servo Drives, and Automation Controllers
- Power Supplies, Energy Management Systems, and Solar Inverters
- Commercial Vehicle Electronics and Agricultural Equipment Controllers
Order & Shipping Info
| Minimum Order Quantity (MOQ) | 1 Piece |
|---|---|
| Shipping Time | Shipped within 1‑2 business days |
| Delivery Time | 3‑7 working days worldwide |
| Shipping Methods | DHL, UPS, FedEx, EMS |
| Payment Methods | T/T (Bank Transfer), PayPal, Credit Card, Western Union |
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
Frequently Asked Questions
Q1: What core does SAK‑XC2365B‑40F80LR‑AB use?
A: It adopts Infineon 16/32‑bit C166SV2 core, maximum operating frequency 80 MHz with DSP MAC instructions.
Q2: What is its operating temperature range?
A: Automotive‑grade AEC‑Q100 qualification, operating temperature: -40°C ~ +125°C.
Q3: What package is SAK‑XC2365B‑40F80LR‑AB?
A: PG‑LQFP‑100‑8 (14×14 mm), surface‑mount, supplied in Tape & Reel packaging.
Q4: Is this MCU still in production?
A: This part is officially End‑of‑Life / Obsolete. Suitable for BOM maintenance and after‑sales repair, not recommended for new designs.
Q5: What are the recommended alternative parts?
A: For new automotive projects, migrate to Infineon AURIX TC2xx / TC3xx series. Contact us for detailed model comparison.
Q6: What do the suffixes in part number mean?
A: SAK = automotive qualification; LR = temperature/package variant; AB = factory configuration variant. Different suffixes cannot be directly substituted without hardware & firmware verification.
Q7: Where to get datasheet, footprint and bulk quotation?
A: Submit our inquiry form for datasheet, CAD files, stock check and volume pricing.
