SN74LVC1G240DBVR
SN74LVC1G240DBVR
Basic Information
| Part Number | SN74LVC1G240DBVR |
| Manufacturer | Texas Instruments |
| Category | Integrated Circuits (ICs) > Logic > Buffers, Drivers, Receivers, Transceivers |
| Description | IC SINGLE 1-BIT INVERTING BUFFER 6-SOT23, Single Bus Interface Inverting Buffer with 3-State Output |
Product Overview
The SN74LVC1G240DBVR is a single-channel, inverting logic buffer with 3-state output designed for low-voltage digital signal buffering and bus interface applications. It operates over a wide voltage range, supports high-speed signal transmission, and is fully compatible with TTL and CMOS logic levels. The device features balanced output drivers, high noise immunity, and low power consumption, with 3-state control for easy bus sharing. Housed in a tiny 6-SOT23 surface-mount package, it is optimized for compact portable electronics, IoT devices, and high-density digital circuit designs.
Key Specifications
| RoHS | RoHS Compliant |
| EDA/CAD Models | Available (Schematic, PCB Footprint, Symbol) |
| Warranty | 1 Year |
| Brand | Texas Instruments |
| Logic Type | Single Inverting Buffer, 3-State Output |
| Voltage – Supply | 1.65V ~ 5.5V |
| Propagation Delay | Typical 3.8ns |
| Logic Compatibility | TTL, CMOS |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Package / Case | 6-SOT23-6 |
Typical Applications
- Portable Consumer Electronics
- IoT Sensor Nodes
- Digital Signal Buffering
- Microcontroller I/O Interface
- High-Speed Data Communication
- Low-Voltage Logic Systems
- Compact Embedded Designs
- Wearable Electronic Devices
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
