SPC563M64L5COAR
SPC563M64L5COAR
| Part Number | SPC563M64L5COAR |
|---|---|
| Manufacturer | STMicroelectronics |
| Category | Integrated Circuits (ICs) > Embedded – Microcontrollers |
| Description | SPC56 M-Line 32-bit Automotive Microcontroller, 80MHz e200z3 Core, 1.5MB Flash, 96KB RAM, integrated eTPU2, enhanced ADC, and dual FlexCAN for powertrain and transmission control. |
| Stock Status | In Stock |
| Origin | Original Factory |
Product Overview
The SPC563M64L5COAR is a 32-bit automotive microcontroller from ST SPC56 M-Line series. It adopts 80 MHz e200z3 Power Architecture RISC core, equipped with 1.5MB ECC-protected Flash and 96KB RAM. Integrated eTPU2, eQADC and dual FlexCAN interfaces, it meets strict AEC-Q100 Grade 1 automotive standards, perfectly suited for automotive powertrain, transmission control and high-reliability industrial applications.
Core Advantages
High-Performance e200z3 Core with FPU
Utilizes the robust 32-bit e200z3 RISC core integrated with a dedicated hardware Floating Point Unit (FPU), enabling rapid native execution of complex mathematical functions and closed-loop algorithm computations with minimal latency.
Dual Enhanced Time Processor Units (eTPU2)
Houses two autonomous on-chip timer coprocessors running independently of the primary CPU core. These units handle highly critical time-to-angle calculations, fuel injection timing, and complex PWM generation without stealing CPU processing overhead.
Comprehensive Safety Management (ECC)
Features embedded hardware Error Correction Code (ECC) protection across all internal Flash and RAM memory spaces, actively identifying and mitigating single-bit faults to guarantee adherence to rigorous safety standards.
Advanced Embedded Analog Infrastructure (eQADC)
Integrates dual enhanced queued analog-to-digital converter matrices capable of fast, high-resolution continuous sensor capturing, completely automated by hardware commands to eliminate manual software polling routines.
Key Specifications
| Brand | STMicroelectronics |
|---|---|
| RoHS Status | RoHS Compliant / Lead-Free Standard (Green Package) |
| EDA/CAD Model | 3D Model & PCB Footprint Available upon request |
| Warranty | 1-Year Standard Factory Warranty |
| Package / Case | LQFP-144 (20x20x0.5mm ) |
| Mounting Type | Surface Mount Technology (SMD/SMT) |
| Surface Marking / Silkscreen | SPC563M64L5 Marking |
| Core Architecture | 32-bit Power Architecture® e200z3 Book E Core |
| Maximum Clock Frequency | 80 MHz Performance Grade |
| On-Chip Program Flash | 1.5 MB with ECC Protection |
| On-Chip System SRAM | 96 KB Total SRAM (including 64 KB General Purpose + 32 KB eTPU RAM) |
| Coprocessor Timers | 2x eTPU2 (Enhanced Time Processor Units) with 64 Channels total |
| Analog-to-Digital Subsystem | Dual eQADC Modules (Up to 40 channels, 12-bit conversion resolution) |
| Network Communication Ports | 2x FlexCAN (CAN 2.0B Active) Modules, 3x LINflex Controllers, 3x DSPI Channels |
| Supply Voltage Requirement | 3.15V to 5.25V External Supply Range (supports internal 1.2V core regulation) |
| Operating Temperature Range | -40°C to +125°C (AEC-Q100 Grade 1 Automotive System Qualification) |
Typical Applications
- Automotive Engine Control Units (ECU) for gasoline and diesel direct injection engines
- Advanced Automatic, Dual-Clutch, and Continuously Variable Transmission Control Modules (TCU)
- Electric Vehicle (EV) and Hybrid Vehicle (HEV) Inverter Controllers and Battery Supervisors
- Aerospace Fly-by-Wire Actuator Nodes, Telemetry Control, and Subsystem Governance
- Rugged Heavy Industrial High-Axis Motor Motion Drives and Programmable Logic Controllers (PLC)
Order & Shipping Info
| Minimum Order Quantity (MOQ) | 1 Piece |
|---|---|
| Shipping Time | Shipped within 1-2 business days |
| Delivery Time | 3-7 working days worldwide |
| Shipping Methods | DHL, UPS, FedEx, EMS |
| Payment Methods | T/T (Bank Transfer), PayPal, Credit Card, Western Union |
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
Frequently Asked Questions
Q1: Is your stock inventory of the SPC563M64L5COAR completely genuine and original?
A: Yes, we guarantee that all SPC563M64L5COAR microcontrollers in our inventory are 100% brand-new, factory-original products from STMicroelectronics, stored and handled under strict ESD anti-static and dry-packaging moisture guidelines.
Q2: What is decoded by the specific suffix designators “COAR” in this part number?
A: “C” stands for AEC-Q100 Grade 1 automotive temperature range (-40°C ~ +125°C). “O” refers to package variant, “A” is silicon revision, and “R” indicates tape and reel packaging form for mass production.
Q3: How does the standalone eTPU2 microengine enhance powertrain software efficiency?
A: The eTPU2 functions as an autonomous, dedicated timer coprocessor with its own hardware execution pipeline. It directly processes real-time angle-stamped events and calculates exact firing or injection widths independently. This keeps the primary e200z3 core free to run system diagnostics and strategy logic without interruption.
Q4: How can our engineering group request full structural pin-out sheets, register reference manuals, or custom wholesale pricing grids?
A: Please complete our Quick Inquiry web form on this page with details about your processing parameters. Our application support desk will process your inquiry and dispatch the available technical documentation package within 24 hours.
