TCAN1042HVDR
TCAN1042HVDR
| Part Number | TCAN1042HVDR |
|---|---|
| Manufacturer | Texas Instruments Incorporated |
| Category | Integrated Circuits (ICs) > Interface > CAN Bus Transceivers |
| Description | HIGH-VOLTAGE CAN TRANSCEIVER, 3.3V/5V, 5Mbps, -40 TO 125 DEG C, 8-SOIC |
Product Overview
The TCAN1042HVDR is an industrial-grade, high-voltage Controller Area Network (CAN) transceiver from Texas Instruments, designed for robust and high-speed communication in harsh automotive and industrial environments. Fully compliant with ISO 11898-2:2016 and supporting data rates up to 5 Mbps, this device serves as the critical interface between CAN controllers and the physical CAN bus. It supports both 3.3V and 5V logic interfaces, offering exceptional design flexibility for modern microcontroller systems. The TCAN1042HVDR features integrated bus fault protection up to ±42V, ultra-low standby current, and advanced protection against ESD, short-circuits, and thermal damage. With outstanding electromagnetic compatibility (EMC) performance, it ensures reliable data transmission without interference. Packaged in a compact 8-SOIC form factor and operating over a wide temperature range of -40°C to +125°C, this transceiver is ideal for mission-critical applications requiring high-voltage tolerance and high-speed CAN connectivity.
Key Specifications
| Parameter | Value |
|---|---|
| RoHS | Compliant (RoHS 2/3 Compliant, Lead-Free) |
| EDA/CAD Models | Available (Gerber, STEP, IDF, Symbol, Footprint) |
| Warranty | 3 Years Standard Warranty |
| Brand | Texas Instruments (TI) |
| Protocol | High-Speed CAN (ISO 11898-2:2016) |
| Data Rate | Up to 5 Mbps |
| Logic Supply | 3.3V ±0.3V, 5V ±0.5V |
| Bus Fault Protection | ±42V Absolute Maximum |
| Operating Temperature Range | -40°C to +125°C (Automotive/Industrial Grade) |
| Package Type | 8-SOIC (Small Outline Integrated Circuit) |
| Standby Current | 5µA (Typ) |
| ESD Protection | ±15kV HBM on CAN Bus Pins |
| Key Features | Undervoltage Lockout, Thermal Shutdown, Bus Dominant Timeout |
Typical Applications
- Automotive Body Control Modules and Infotainment Systems
- Industrial Automation and CANopen Networks
- Electric Vehicle (EV) Battery Management Systems (BMS)
- Factory Robotics and Motion Control Systems
- High-Speed Industrial Sensor Networks
- Automotive ADAS and Powertrain Controls
- Building Automation and HVAC Systems
- Embedded Systems with 3.3V/5V Microcontroller Interfaces
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
