TDA8566Q
TDA8566Q
| Part Number | TDA8566Q |
|---|---|
| Manufacturer | NXP Semiconductors |
| Category | Integrated Circuits (ICs) > Audio > Amplifiers > Class AB |
| Description | 4-CHANNEL BRIDGE/STEREO AUDIO POWER AMPLIFIER, 12V-18V, 22W, -40 TO 125 DEG C, 20-SOIC |
Product Overview
The TDA8566Q is a high-performance 4-channel audio power amplifier from NXP Semiconductors, designed for automotive and industrial audio applications. This Class AB amplifier supports both bridge-tied load (BTL) and stereo configurations, delivering high-quality audio output with low distortion and high efficiency. Operating over a wide supply voltage range of 12V to 18V, it provides up to 22W per channel (bridge mode) and features built-in thermal shutdown, short-circuit protection, and over-voltage protection for reliable operation in harsh environments. The device offers excellent audio characteristics including low noise, high signal-to-noise ratio, and minimal cross-talk between channels. With a compact 20-SOIC package and extended temperature range (-40°C to +125°C), the TDA8566Q is optimized for automotive infotainment, car audio systems, and industrial audio equipment requiring robust multi-channel amplification.
Key Specifications
| Parameter | Value |
|---|---|
| RoHS | Compliant (RoHS 2/3 Compliant, Lead-Free) |
| EDA/CAD Models | Available (Gerber, STEP, IDF, Symbol, Footprint) |
| Warranty | 3 Years Standard Warranty |
| Brand | NXP Semiconductors |
| Amplifier Type | Class AB, 4-Channel |
| Output Power | 22W/Channel (Bridge Mode), 6W/Channel (Stereo) |
| Supply Voltage | 12V to 18V |
| Operating Temperature | -40°C to +125°C (Automotive Grade) |
| Package Type | 20-SOIC (Small Outline Integrated Circuit) |
| Configuration | Bridge-Tied Load (BTL) / Stereo |
| THD+N | < 0.1% (Typ) |
| Protection Features | Thermal Shutdown, Short-Circuit, Over-Voltage |
| Signal-to-Noise Ratio | 90dB (Typ) |
Typical Applications
- Automotive Audio Systems and Infotainment Head Units
- Car Door Speakers and Multi-Channel Sound Systems
- Marine Audio Equipment
- Industrial Audio and Public Address Systems
- Aftermarket Vehicle Audio Amplifiers
- Automotive Rear-Seat Entertainment Systems
- Professional Audio Equipment
- 12V/18V Battery-Powered Audio Devices
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
