TJA1050T/CM,118
TJA1050T/CM,118
| Part Number | TJA1050T/CM,118 |
|---|---|
| Manufacturer | NXP Semiconductors |
| Category | Integrated Circuits (ICs) > Interface > CAN Bus Transceivers |
| Description | HIGH-SPEED CAN TRANSCEIVER, 5V, 1MBPS, -40 TO 125 DEG C, 8-SOIC |
Product Overview
The TJA1050T/CM,118 is a high-speed Controller Area Network (CAN) transceiver from NXP Semiconductors, designed for reliable communication in automotive and industrial CAN bus systems. This device provides the interface between the CAN protocol controller and the physical two-wire CAN bus, supporting data rates up to 1 Mbps and fully compliant with the ISO 11898-2 standard. Operating from a single 5V supply voltage, the TJA1050 features built-in protection against short-circuit, over-temperature, and electrostatic discharge (ESD), ensuring robust performance in harsh electrical environments. With low electromagnetic emission (EME) and high electromagnetic immunity (EMI), it enables stable and interference-free communication. The device offers silent and slope control modes for optimized power consumption and signal quality. Packaged in an 8-SOIC form factor, it operates over a wide temperature range of -40°C to +125°C, making it ideal for automotive, industrial automation, and transportation applications requiring dependable high-speed CAN communication.
Key Specifications
| Parameter | Value |
|---|---|
| RoHS | Compliant (RoHS 2/3 Compliant, Lead-Free) |
| EDA/CAD Models | Available (Gerber, STEP, IDF, Symbol, Footprint) |
| Warranty | 3 Years Standard Warranty |
| Brand | NXP Semiconductors |
| Protocol | High-Speed CAN (ISO 11898-2) |
| Data Rate | Up to 1 Mbps |
| Supply Voltage | 4.5V to 5.5V (Typ 5V) |
| Operating Temperature Range | -40°C to +125°C (Automotive Grade) |
| Package Type | 8-SOIC (Small Outline Integrated Circuit) |
| Bus Fault Protection | ±36V Short-Circuit Protection |
| ESD Protection | ±8kV HBM on Bus Pins |
| Supply Current | 45mA (Max) Active, 15μA (Max) Standby |
| Features | Slope Control, Silent Mode, Thermal Shutdown |
Typical Applications
- Automotive Electronics (Body Control, Infotainment, Powertrain Systems)
- Industrial Automation and CAN-Based Control Networks
- Robotics and Factory Automation Equipment
- Automotive Diagnostic and Test Tools
- Electric Vehicle (EV) Battery Management Systems
- Building Automation and HVAC Control Systems
- Marine and Transportation Communication Systems
- Embedded Systems with CAN Bus Interfaces
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
