TSUMV53RUU-Z1
TSUMV53RUU-Z1
| Part Number | TSUMV53RUU-Z1 |
|---|---|
| Manufacturer | MStar Semiconductor (MediaTek) |
| Category | Integrated Circuits (ICs) > Interface – TV and Video Processors / LCD Controllers |
| Description | High-Integration LCD TV Controller IC with Integrated Multi-Standard Video Decoder, HDMI/VGA Inputs, Audio Demodulator, USB Multimedia Playback Engine, and LVDS Transmitter. |
| Stock Status | In Stock |
| Origin | Original Factory |
Product Overview
The TSUMV53RUU-Z1 is a highly integrated single-chip TV multimedia display processor developed by MStar Semiconductor (MediaTek). Designed for low-cost 1080p display solutions including TV motherboards and commercial advertising screens. It integrates analog demodulation, multi-format video decoding, audio processing and LVDS output. Built-in 32-bit RISC CPU, it supports HDMI 1.4, USB 2.0, CVBS and other interfaces, effectively simplifying peripheral circuit layout and lowering overall BOM cost.
Core Advantages
Highly Integrated Single-Chip Solution
Integrates video decoding, HDMI receiving, audio processing and LVDS panel driver on a single chip, reducing PCB area and component quantity.
Powerful Multimedia Decoding Function
Supports mainstream video, audio and image formats via USB 2.0, enabling direct media playback without external host processor.
Advanced Image Processing Engine
Equipped with 3D de-interlacing, noise reduction and color management algorithms to deliver stable and clear Full HD display effect.
Rich Input Interface Compatibility
Supports HDMI 1.4, VGA, CVBS and SCART inputs to satisfy connection demands of televisions and commercial display devices.
Key Specifications
| Brand / Series | MStar Semiconductor / MediaTek, TSUMV53 Series |
|---|---|
| RoHS Status | RoHS Compliant / Lead-Free |
| EDA/CAD Model | Schematic symbol models, 3D CAD step profiles, and LQFP footprint land patterns are available on request |
| Warranty | 1-Year Standard Quality Warranty |
| Package / Case | LQFP-128 / QFN-128 (Two package versions available, confirm before ordering) |
| Mounting Type | Surface Mount (SMT / SMD) |
| Surface Marking / Silkscreen | TSUMV53RUU-Z1 / MStar logo, Marking |
| CPU Core | 32-bit RISC Processor |
| Video Decoding Standard | H.264 (High Profile L4.1), MPEG-2/4, VC1, Partial HEVC Subset |
| Max Output Resolution | Full HD Up to 1920 × 1080 @ 30fps |
| Panel Output Interface | Dual-Channel / Single-Channel 8/10-bit LVDS Transmitter |
| Video Front-End Inputs | 3 × HDMI 1.4 (Support ARC), CVBS, SCART, 2 × USB 2.0 Interface |
| Analog TV Demodulator | Built-in PAL/NTSC/SECAM multi-standard demodulator, 3D Comb Filter |
| Audio Processing | Integrated Audio DSP, Supports MP3/AAC/AC3 decoding, Partial version with 2×8W Class D Amplifier, S/PDIF output, Analog Audio I/O |
| USB Media Playback | Supports MP4, AVI, MKV video formats, MP3 audio, and JPEG/PNG image display |
| External Memory Support | External DDR / DDR2 memory required |
| Supply Voltage | 1.2V Core / 3.3V I/O Power Supply Architecture |
| Operating Temperature Range | -10°C ~ +80°C (Commercial Grade) |
| Packaging Format | Tray / Tape & Reel |
Typical Applications
- LCD / LED TV mainboards and portable television displays
- Commercial advertising display boards, digital signage monitors, and kiosks
- Industrial control displays, multi-input desktop monitors, and security viewports
- Educational multimedia projectors, interactive whiteboards, and presentation displays
- Smart mirror display panels and embedded commercial video player units
Order & Shipping Info
| Minimum Order Quantity (MOQ) | 1 Piece |
|---|---|
| Shipping Time | Shipped within 1-2 business days |
| Delivery Time | 3-7 working days worldwide |
| Shipping Methods | DHL, UPS, FedEx, EMS |
| Payment Methods | T/T (Bank Transfer), PayPal, Credit Card, Western Union |
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
Frequently Asked Questions
Q1: What is the primary function of the TSUMV53RUU-Z1 processor?
A: The TSUMV53RUU-Z1 is a dedicated display controller IC for TV mainboards and advertising monitors. It processes video input signals, executes image optimization, and outputs driving signals to Full HD LCD panels via LVDS interface.
Q2: Does the TSUMV53RUU-Z1 support USB media playback directly?
A: Yes. It integrates USB 2.0 host controller and hardware decoder, supporting direct playback of video, audio and image files from USB flash drive without external main CPU.
Q3: What panel interface types are supported by this controller?
A: It supports single/dual-channel 8/10-bit LVDS transmitter, compatible with mainstream HD (1366 × 768) and Full HD (1920 × 1080) TFT-LCD panels.
Q4: Are firmware customization and datasheet documentation available for this chip?
A: Yes. Detailed datasheets, pinout diagrams, schematic guides and reference firmware information can be provided via our Quick Inquiry system.
Q5: What is the difference between TSUMV53RUU-Z1 and TSUMV53RWU-Z1?
A: They belong to the same V53 series with partial function differences. TSUMV53RWU-Z1 usually supports wider temperature range and different interface allocation, you can consult us for detailed comparison parameters.
Q6: Does TSUMV53RUU-Z1 require external memory chips to work?
A: Yes, this chip needs to be matched with external DDR / DDR2 memory, it does not embed large-capacity memory inside.
Q7: Can TSUMV53RUU-Z1 be used for industrial display equipment?
A: Standard version is commercial grade (-10℃ ~ +80℃). For long-term industrial environment use, we recommend confirming temperature requirements before design-in.
Q8: How many HDMI input ports does TSUMV53RUU-Z1 support?
A: Built-in 3 groups of HDMI 1.4 interfaces with ARC function, also compatible with CVBS, SCART and VGA signal input.
