5AGXFA5H4F35C4G
5AGXFA5H4F35C4G
| Part Number | 5AGXFA5H4F35C4G |
|---|---|
| Manufacturer | Intel (Altera) |
| Category | Integrated Circuits (ICs) > Embedded – FPGAs (Field Programmable Gate Array) |
| Description | Arria V GX FPGA featuring 190K Logic Elements, 544 Multipliers, and 16 High-Speed Transceivers, optimized for bandwidth-intensive industrial and wireless designs. |
| Stock Status | In Stock |
| Origin | Original Factory |
Product Overview
The 5AGXFA5H4F35C4G is a high-density, low-power Field Programmable Gate Array (FPGA) within Intel’s (formerly Altera) Arria® V GX architecture series. Purpose-built to balance high transceiver bandwidth, processing efficiency, and minimized power consumption, this 28nm device features 190,000 logic elements and a rich array of integrated hard intellectual property (IP) macros. The Arria V GX core logic is coupled seamlessly with 16 hardware transceiver channels capable of handling serialization data rates up to 6.375 Gbps, supporting streamlined integration with contemporary backhaul network layouts. With advanced variable-precision DSP blocks and hardened memory controllers, the provides a comprehensive programmable system-on-chip foundation for multi-channel video broadcasting, high-frequency software-defined radio, automated machine vision routing, and commercial aerospace telemetry networks requiring high reliability.
Core Advantages
Optimized Power-to-Performance Ratio
Fabricated on a low-leakage 28nm TSMC process, combining architectural clock-gating mechanisms to achieve exceptionally low static and dynamic power draw while sustaining high hardware processing clock domains.
High-Bandwidth Serial Transceiver Matrix
Houses 16 integrated 6.375 Gbps transceivers alongside dedicated hard PCI Express Gen2 IP blocks, allowing for direct integration with multi-gigabit protocols without consuming programmable fabric routing.
Variable-Precision DSP Architecture
Integrates advanced hardware DSP blocks that can be configured on-the-fly to execute either high-precision 18-bit floating-point math or dense dual 9-bit fixed-point matrices, optimizing algorithmic acceleration for filter pipelines.
Robust Hardware Memory Controllers
Features hardened physical memory interface layers (PHY) supporting fast interfacing to DDR3 and LPDDR2 storage profiles, achieving deterministic local cache bandwidth with minimum design complexity.
Key Specifications
| Brand | Intel (Altera) |
|---|---|
| RoHS Status | RoHS Compliant / Lead-Free Standard (Green Package Format) |
| EDA/CAD Model | 3D Model & PCB Footprint Available upon request |
| Warranty | 1-Year Standard Factory Warranty |
| Package / Case | FBGA-1152,FC(35x35mm) |
| Mounting Type | Surface Mount Technology (SMD/SMT) |
| Surface Marking / Silkscreen | 5AGXFA5H4F35C4G Marking |
| FPGA Family Subsystem | Arria® V GX Variant |
| Total Logic Elements (LE) | 190,000 Elements |
| ALMs (Adaptive Logic Modules) | 71,698 ALMs |
| Total Internal Embedded Memory | 13.2 Mbits (M10K blocks and distributed RAM) |
| Variable-Precision DSP Slices | 544 Hard Multiplier Blocks |
| High-Speed Transceiver Links | 16x Transceivers running up to 6.375 Gbps |
| Maximum Digital User I/O Pins | 544 Available I/O pins |
| Operating Voltage Range | 1.07V to 1.13V DC Core Voltage Rail (1.10V Nominal) |
| Operating Temperature Range | 0°C to +85°C (Commercial Grade Operation Window) |
Typical Applications
- Wireless Base Station Transceivers, Remote Radio Heads (RRH), and Long-Haul Backhaul Arrays
- High-Definition Video Broadcasting Systems, Studio Video Switchers, and Image Capture Processing
- High-Resolution Machine Vision Cameras, Industrial Automated Assembly, and Sorting Lines
- Advanced Signal Test Equipment, Digital Oscilloscopes, and Multi-Channel Logic Analyzers
- Military Radar Processing Systems, Secure Software-Defined Radio (SDR), and Sonar Arrays
Order & Shipping Info
| Minimum Order Quantity (MOQ) | 1 Piece |
|---|---|
| Shipping Time | Shipped within 1-2 business days |
| Delivery Time | 3-7 working days worldwide |
| Shipping Methods | DHL, UPS, FedEx, EMS |
| Payment Methods | T/T (Bank Transfer), PayPal, Credit Card, Western Union |
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
Frequently Asked Questions
Q1: Is your current stock inventory of the 5AGXFA5H4F35C4G completely original and new?
A: Yes, we guarantee that all 5AGXFA5H4F35C4G FPGAs in our inventory are 100% brand-new, authentic factory-original products from Intel (Altera), stored and handled strictly under dry anti-static ESD shielding guidelines.
Q2: What is decoded by the suffix characters “C4G” inside this Arria V part number?
A: The “C” stands for commercial temperature grade (0°C to +85°C); “4” represents speed grade 4; “G” indicates lead-free and RoHS compliant packaging.
Q3: Does this specific FPGA incorporate hardened IP cores for PCI Express?
A: Yes. The 5AGXFA5H4F35C4G features a dedicated hardware macro block supporting PCI Express Gen2 x4 or Gen1 x8 protocols, ensuring reliable streaming throughput without eating up the device’s soft logic cells.
Q4: How can our engineering desk request specific pin-out descriptions, IBIS simulation code data, or Quartus compilation layout advice?
A: Please complete our Quick Inquiry web form on this page with details about your processing parameters. Our application support desk will process your inquiry and dispatch the available technical documentation package within 24 hours.
