AD22293Z-RL7
AD22293Z-RL7
| Part Number | AD22293Z-RL7 |
|---|---|
| Manufacturer | Analog Devices Inc. |
| Category | Sensors & Transducers > Motion Sensors > Accelerometers |
| Description | IC ACCELEROMETER PRECISION ±1.7G/±5G/±18G DUAL AXIS ,LCC-8(5x5mm) Package |
Product Overview
The AD22293Z-RL7 is a high-performance, dual-axis analog MEMS accelerometer from Analog Devices, designed for precision motion and vibration sensing applications. It offers selectable acceleration ranges of ±1.7g, ±5g, and ±18g with a typical sensitivity of 312 mV/g, delivering accurate analog outputs proportional to acceleration. The device features a built-in temperature sensor, adjustable bandwidth, and low noise performance, making it ideal for industrial, automotive, and consumer applications requiring reliable acceleration measurement.
Core Advantages
- Selectable Acceleration Ranges: Supports ±1.7g, ±5g, and ±18g for flexible application needs
- High Sensitivity: 312 mV/g typical sensitivity (293-331 mV/g range) for precise acceleration measurement
- Dual-Axis Operation: Simultaneous X and Y axis acceleration sensing
- Adjustable Bandwidth: 0.5 Hz to 2.5 kHz adjustable bandwidth for flexible applications
- Wide Operating Voltage: 3V to 6V supply range, compatible with 3.3V and 5V systems
- Robust Packaging: LCC-8(5x5mm) surface-mount package for industrial environments
- Extended Temperature Range: Operating range from -40°C to +125°C
Key Specifications
| Parameter | Specification |
|---|---|
| Brand | Analog Devices Inc. |
| RoHS Status | RoHS Compliant |
| EDA/CAD Models | Available upon request |
| Warranty | 1 Year |
| Package / Case | LCC-8(5x5mm) |
| Mounting Type | Surface Mount |
| Acceleration Range | ±1.7g, ±5g, ±18g (Selectable) |
| Sensitivity | 312 mV/g (Typical, 293-331 mV/g Range) |
| Bandwidth | 0.5 Hz ~ 2.5 kHz (Adjustable) |
| Supply Voltage | 3.0 V ~ 6.0 V |
| Operating Temperature | -40°C ~ 125°C |
| Current Consumption | 700 μA (Typical @ 5V) |
Typical Applications
- Industrial Equipment Vibration Monitoring
- Tilt and Inclination Sensing
- Automotive Body Dynamics and Safety Systems
- Portable Device Motion Detection
- Condition Monitoring and Predictive Maintenance
- Robotics Motion Control and Stability Systems
Order & Shipping Info
- Minimum Order Quantity (MOQ): 1 Piece
- Shipping Time: Shipped within 1-2 business days
- Delivery Time: 3-7 working days worldwide
- Shipping Methods: DHL, UPS, FedEx, EMS
- Payment Methods: T/T (Bank Transfer), PayPal, Credit Card, Western Union
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
Frequently Asked Questions
Q: What acceleration ranges does the AD22293Z-RL7 support?
A: The AD22293Z-RL7 offers selectable acceleration ranges of ±1.7g, ±5g, and ±18g, suitable for diverse industrial and consumer motion sensing applications.
Q: What is the typical sensitivity of this accelerometer?
A: The typical sensitivity is 312 mV/g, with a range of 293-331 mV/g, providing high-resolution analog output proportional to acceleration.
Q: What package does the AD22293Z-RL7 come in?
A: It is packaged in an LCC-8(5x5mm) surface-mount package, ideal for automated assembly and compact designs.
Q: What is the operating voltage range of the AD22293Z-RL7?
A: The device operates from 3V to 6V, making it compatible with both 3.3V and 5V system designs.
Q: Is the AD22293Z-RL7 RoHS compliant?
A: Yes, the AD22293Z-RL7 is RoHS compliant, meeting environmental standards for lead-free manufacturing.
