AD7705BRUZ-REEL7
AD7705BRUZ-REEL7
| Part Number | AD7705BRUZ-REEL7 |
|---|---|
| Manufacturer | Analog Devices Inc. |
| Category | Analog-to-Digital Converters; 16-Bit Sigma-Delta ADCs |
| Description | 16-Bit Sigma-Delta ADC, Dual Differential Inputs, PGA, SPI Interface, TSSOP-16 Package |
Product Overview
The AD7705BRUZ-REEL7 is a high-precision 16-bit sigma-delta analog-to-digital converter optimized for low-frequency measurement applications such as weigh scales, industrial sensors, and process control. It features two fully differential input channels, an integrated programmable gain amplifier (PGA), a precision reference buffer, and a flexible SPI serial interface. The device delivers excellent linearity, low noise, and high accuracy across temperature, making it ideal for high-resolution measurement of bridge-type sensors (strain gauges, load cells, pressure sensors). With built-in digital filtering and low power consumption, it provides reliable performance in industrial and embedded measurement systems. Housed in a compact TSSOP-16 surface-mount package, it supports space-efficient PCB design.
| Key Specifications | |
|---|---|
| RoHS Status | RoHS Compliant |
| EDA / CAD Models | 3D Model, Symbol, Footprint Available |
| Warranty | 2-Year Warranty |
| Brand | Analog Devices |
| Resolution | 16-Bit Sigma-Delta |
| Input Channels | 2 Differential Inputs |
| Interface | SPI / QSPI Compatible |
| Package Type | TSSOP-16 |
| Operating Temperature | -40°C to +105°C |
Typical Applications
- Precision Weigh Scales & Load Cell Systems
- Industrial Process Control & Monitoring
- Strain Gauge & Pressure Sensor Interfaces
- Data Acquisition Systems (DAS)
- Smart Sensor Modules & Transmitters
- Portable Measurement Instruments
- Industrial Automation & Control Systems
- High-Resolution Low-Frequency Sensing
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
