ADP3110AKRZ-RL
ADP3110AKRZ-RL
| Part Number | ADP3110AKRZ-RL |
|---|---|
| Manufacturer | onsemi |
| Category | Power Management ICs; MOSFET Drivers |
| Description | Dual High-Speed MOSFET Driver, 4A Peak Output, 4.5V-15V, SOIC-8 Package |
Product Overview
The ADP3110AKRZ-RL is a high-speed, dual-channel MOSFET driver designed for high-efficiency power conversion applications including DC-DC converters, switching power supplies, and motor drive systems. It delivers 4A peak sink/source current for fast switching of power MOSFETs, operates from 4.5V to 15V supply voltage, and features matched propagation delays for stable synchronous rectification. Built with robust ESD protection, thermal shutdown, and overcurrent protection, this driver ensures reliable operation in industrial and commercial power systems. Housed in a compact SOIC-8 surface-mount package, it enables high-density PCB integration and high-frequency switching performance.
| Key Specifications | |
|---|---|
| RoHS Status | RoHS Compliant |
| EDA / CAD Models | 3D Model, Symbol, Footprint Available |
| Warranty | 2-Year Warranty |
| Brand | onsemi |
| Output Current | 4A Peak Sink/Source |
| Supply Voltage | 4.5V ~ 15V |
| Channels | Dual Independent Driver Channels |
| Package Type | SOIC-8 |
| Operating Temperature | -40°C to +125°C |
Typical Applications
- High-Frequency DC-DC Switching Converters
- Synchronous Rectifier Power Supplies
- MOSFET/IGBT Drive Circuits
- Industrial Power Inverters
- Battery-Powered Power Systems
- High-Efficiency Motor Drivers
- High-Density Power Modules
- Automotive and Industrial Power Controls
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
