ADS1114IDGSR
ADS1114IDGSR
| Part Number | ADS1114IDGSR |
|---|---|
| Manufacturer | Texas Instruments |
| Category | Analog-to-Digital Converters; 16-Bit I2C ADCs |
| Description | 16-Bit Precision I2C ADC, Differential Input, PGA, Internal Reference, VSSOP-10 Package |
Product Overview
The ADS1114IDGSR is a high-precision, low-power 16-bit analog-to-digital converter (ADC) with a standard I2C interface, designed for high-accuracy measurement in industrial, medical, and portable systems. It integrates a programmable gain amplifier (PGA), precision internal voltage reference, and oscillator, supporting differential analog inputs and adjustable data rates up to 860 SPS. The device offers ultra-low noise, high linearity, and wide voltage operation from 2.0V to 5.5V, making it ideal for low-level sensor signal acquisition. With comprehensive safety features including overvoltage detection and thermal protection, it ensures stable and reliable performance. Housed in a compact VSSOP-10 package, it supports space-efficient PCB integration for high-density designs.
| Key Specifications | |
|---|---|
| RoHS Status | RoHS Compliant |
| EDA / CAD Models | 3D Model, Symbol, Footprint Available |
| Warranty | 2-Year Warranty |
| Brand | Texas Instruments |
| Resolution | 16-Bit |
| Interface | I2C |
| Package Type | VSSOP-10 |
| Operating Temperature | -40°C to +125°C |
Typical Applications
- High-Precision Sensor Signal Conditioning
- Industrial Process Control & Monitoring
- Portable & Battery-Powered Measurement Devices
- Medical Instrumentation & Wearable Devices
- Temperature, Pressure & Load Cell Interfaces
- IoT Nodes & Smart Sensor Modules
- Data Acquisition Systems (DAS)
- Low-Level Analog Signal Measurement
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
