ALXD800EEXJ2VD C3
ALXD800EEXJ2VD C3
| Part Number | ALXD800EEXJ2VD C3 |
|---|---|
| Manufacturer | AMD / Geode (Advanced Micro Devices) |
| Category | Integrated Circuits (ICs) > Embedded – Microprocessors |
| Description | Geode LX800 x86 processor operating at 500MHz with integrated graphics, memory controller, and ultra-low power consumption, C3 stepping. |
| Stock Status | In Stock |
| Origin | Original Factory |
Product Overview
The ALXD800EEXJ2VD C3 is a highly integrated, ultra-low-power x86-compatible embedded microprocessor belonging to the legendary AMD Geode™ LX processor series. Operating at 500MHz, this C3 stepping silicon architecture provides an exceptional balance of absolute software compatibility and high-efficiency thermal profiles. The chip features a highly optimized monolithic implementation that unifies a high-performance CPU core, an integrated graphics processing unit, a dedicated DDR memory controller, and a high-bandwidth PCI bus interface onto a single die. Specifically designed to operate without bulky active fan coolers, the delivers robust computing capabilities to fanless industrial control computers, human-machine interfaces (HMI), rugged thin-client network terminals, and compact legacy embedded hardware frameworks.
Core Advantages
Native x86 Architecture Software Compatibility
Provides complete structural compatibility with standard x86 software environments. This allows industrial systems to run legacy operating systems and custom proprietary industrial application code smoothly without requiring complex emulation layers or modern code recompilation.
Ultra-Low Thermal Dissipation Profile
Engineered to operate with typical power levels of under a few watts. This low-power architecture enables total reliance on completely passive fanless convection cooling layouts, eliminating dust buildup issues and extending system uptime in harsh environments.
High Subsystem Hardware Integration
By integrating the companion graphics display acceleration engine and a dedicated DDR memory subsystem directly onto the processing silicon, the device shortens traces, maximizes signal integrity, and drastically minimizes overall motherboard BOM space requirements.
Proven Longevity and Lifecycle Reliability
The premium C3 stepping revision provides excellent silicon stability and improved errata fixes. This makes it a preferred choice for long-lifecycle industrial automation, medical systems, and transport infrastructure projects requiring multi-year operational consistency.
Key Specifications
| Brand | AMD (Advanced Micro Devices) |
|---|---|
| RoHS Status | RoHS Compliant / Lead-Free |
| EDA/CAD Model | 3D Model & PCB Footprint Available upon request |
| Warranty | 1-Year Standard Factory Warranty |
| Package / Case | BGA-481 (Plastic Ball Grid Array) |
| Mounting Type | Surface Mount (SMD/SMT) |
| Surface Marking / Silkscreen | ALXD800EEXJ2VD Marking |
| Processor Core | Geode™ LX800 Core |
| Core Frequency Speed | 500 MHz |
| Silicon Revision Stepping | C3 Revision Block |
| Memory Interface Support | Integrated 32-bit DDR1 Memory Controller (Up to DDR400) |
| Integrated Graphics | On-Chip 2D Graphics Accelerator (Supports High-Res CRT & TFT Interfaces) |
| I/O Bus Extensions | Integrated PCI Local Bus and High-Speed USB Controller Interface |
| Typical Power Consumption | < 3 Watts (Extremely high energy efficiency performance) |
| Operating Temperature Range | 0°C to +70°C (Standard Industrial Environment Optimization) |
Typical Applications
- Fanless Industrial Automation Computers, PLCs, and Controller Blocks
- Human-Machine Interfaces (HMI) and Industrial Touchscreen Display Terminals
- Thin Client Terminal Equipment, Network Gateways, and Legacy Firewalls
- Point-of-Sale (POS) Registers and Commercial Self-Service Kiosk Stations
- Transportation Infrastructure Controls, Telematics Systems, and Data Logging Hubs
Order & Shipping Info
| Minimum Order Quantity (MOQ) | 1 Piece |
|---|---|
| Shipping Time | Shipped within 1-2 business days |
| Delivery Time | 3-7 working days worldwide |
| Shipping Methods | DHL, UPS, FedEx, EMS |
| Payment Methods | T/T (Bank Transfer), PayPal, Credit Card, Western Union |
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
Frequently Asked Questions
Q1: Is your currently listed inventory of the ALXD800EEXJ2VD C3 processor completely original?
A: Yes, all ALXD800EEXJ2VD C3 microprocessors in our warehouse are 100% original, brand-new components from original factory production runs, carefully preserved in anti-static tray packaging.
Q2: What is the main structural difference between this part and older silicon steppings?
A: The “C3” designation defines the final, most refined silicon stepping revision of the AMD Geode LX series. It includes improved internal hardware errata fixes, enhanced signal integrity, and exceptional electrical longevity.
Q3: Does the ALXD800EEXJ2VD C3 require active cooling fans on the system assembly?
A: No, thanks to its high-efficiency architecture consuming under 3 watts typically, this microprocessor is optimized for completely fanless equipment layouts, requiring only a basic passive aluminum heat sink block.
Q4: How can our technical design team request the full pinout configuration maps and reference schematic symbols?
A: Please complete our Quick Inquiry web form on this page with details about your interface configuration needs. Our system engineering application desk will email you the technical design package within 24 hours.
