AR0134CSSC00SPCA0-DPBR
AR0134CSSC00SPCA0-DPBR
| Part Number | AR0134CSSC00SPCA0-DPBR |
|---|---|
| Manufacturer | onsemi (ON Semiconductor) |
| Category | Sensors, Transducers > Image Sensors, Camera Modules |
| Description | 1/3‑Inch 1.2 MP Color CMOS Digital Image Sensor with Global Shutter, High Frame Rate, 48‑Pin iLCC(LCC‑48,10×10 mm) Package. |
| Stock Status | In Stock |
| Origin | Original Factory |
Product Overview
The AR0134CSSC00SPCA0‑DPBR is a 1/3‑inch 1.2MP color global‑shutter CMOS image sensor from onsemi. It outputs 1280×960 resolution at up to 54fps, features 3.75 μm pixels for good low‑light performance. It supports 12‑bit parallel and HiSPi serial interfaces, does not support MIPI CSI‑2. Suitable for industrial vision, barcode scanning and motion‑capture applications.
Core Advantages
Global Shutter
Simultaneous pixel exposure, eliminates motion blur for fast‑moving object capture.
Excellent Low‑Light Sensitivity
3.75 μm large pixel delivers low read noise and high quantum efficiency under poor lighting.
Dual Output Interfaces
12‑bit parallel and HiSPi serial output for easy embedded‑system integration, no MIPI CSI‑2 support.
Compact Low‑Power Package
48‑pin iLCC‑48 (10×10 mm) package, low power for portable & space‑limited devices.
Key Specifications
| Brand | onsemi |
|---|---|
| RoHS Status | RoHS Compliant / Lead‑Free |
| EDA / CAD | PCB Footprint & 3D Model Available upon Request |
| Warranty | 1‑Year Standard Quality Warranty |
| Package / Case | 48‑Pin iLCC(LCC‑48,10×10 mm) / Dry Pack with Protective Film |
| Mounting Type | Surface Mount (SMD / SMT) |
| Surface Marking / Silkscreen | AR0134CSSC00SPCA0 |
| Optical Format | 1/3‑Inch (4:3 Aspect Ratio) |
| Active Array Resolution | 1280 (H) × 960 (V) (1.2 Megapixels) |
| Pixel Size | 3.75 µm × 3.75 µm |
| Shutter Type | Global Shutter |
| Color Filter | Color (RGB Bayer Filter Array) |
| Maximum Frame Rate | 54 fps @ 1280×960, 60 fps @ 720p HD |
| Output Interface | Parallel 12‑Bit / HiSPi Serial Interface |
| Input Clock Range | 6‑50 MHz; Max Output Pixel Clock:74.25 MHz |
| Operating Temperature Range | ‑30°C to +70°C (Ambient), ‑30°C ~ +80°C (Junction) |
Typical Applications
- High‑Speed Industrial Barcode Scanning and Automated Logistics Inspection
- Factory Automation, Robotic Vision, and Optical Sorting Equipment
- Gesture Recognition, 3D Spatial Tracking, and AR/VR Tracking Modules
- In‑Vehicle Driver Monitoring Systems (DMS) and Passenger Detection
- Biometric Security Systems, High‑Speed Surveillance, and Drones
Order & Shipping Info
| Minimum Order Quantity (MOQ) | 1 Piece |
|---|---|
| Shipping Time | Shipped within 1‑2 business days |
| Delivery Time | 3‑7 working days worldwide |
| Shipping Methods | DHL, UPS, FedEx, EMS |
| Payment Methods | T/T (Bank Transfer), PayPal, Credit Card, Western Union |
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
Frequently Asked Questions
Q1: Is the AR0134CSSC00SPCA0‑DPBR a monochrome or color image sensor?
A: “CS” suffix stands for color version with RGB Bayer filter. Monochrome variant uses CM suffix.
Q2: What is the main advantage of AR0134 global shutter?
A: Simultaneous pixel exposure, eliminates motion blur and distortion when capturing fast‑moving objects.
Q3: What interfaces does this sensor support?
A: 12‑bit parallel and HiSPi serial output. This iLCC model does NOT support MIPI CSI‑2.
Q4: What do DPBR, TBR, DEVR suffixes mean?
A: DPBR: dry pack with protective film; TBR: tape & reel; DEVR: demo/evaluation kit. Only packaging differs, sensor die function remains identical.
Q5: Can AR0134CSSC00SPCA0‑DPBR directly replace 64‑pin iBGA AR0134?
A: Not drop‑in compatible. This is 48‑pin iLCC‑48 (10×10 mm), iBGA is 64‑pin 9×9 mm. Pinout and PCB footprint differ, hardware redesign required.
Q6: What compatible alternatives are available in AR0134 family?
A: AR0134CMSC00SPCA0‑XX is pin‑compatible monochrome model with identical timing performance, without Bayer color filter, for grayscale‑only projects.
Q7: How to get datasheet, schematic or bulk quotation?
A: Please submit our Quick Inquiry form for datasheets, sample requests and volume pricing.
