BLK-89-S+
BLK-89-S+
| Part Number | BLK-89-S+ |
|---|---|
| Manufacturer | Mini-Circuits |
| Category | RF Limiters; Surface Mount RF Limiter |
| Description | Broadband RF Limiter, 10 – 6000 MHz, 50Ω, Low Insertion Loss, SMD Surface Mount Package |
Product Overview
The BLK-89-S+ is a high-performance broadband surface-mount RF limiter designed for protecting sensitive receiver frontends, amplifiers, and RF components from over-power damage. It operates over an ultra-wide frequency range from 10 MHz to 6000 MHz with ultra-low insertion loss, fast response time, and consistent limiting performance. Built with advanced semiconductor technology and compact SMD packaging, this limiter delivers high reliability, wide temperature stability, and excellent input/output matching for seamless integration into high-density RF systems, communication transceivers, and test equipment.
| Key Specifications | |
|---|---|
| RoHS Status | RoHS Compliant |
| EDA / CAD Models | 3D Model, Symbol, Footprint Available |
| Warranty | 2-Year Warranty |
| Brand | Mini-Circuits |
| Frequency Range | 10 – 6000 MHz |
| Impedance | 50Ω |
| Insertion Loss | 0.35 dB Typical |
| Package Type | SMD Surface Mount |
| Operating Temperature | -40°C to +85°C |
Typical Applications
- RF Receiver Front-End Protection
- Low Noise Amplifier (LNA) Protection
- Broadband Wireless Communication Systems
- Test & Measurement Instrumentation
- Microwave & RF Signal Conditioning
- Portable & Battery-Powered RF Devices
- High-Density RF PCB Designs
- Industrial & Commercial RF Modules
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
