CS5530A-UCE
CS5530A-UCE
| Part Number | CS5530A-UCE |
|---|---|
| Manufacturer | AMD (Manufactured by National Semiconductor/NS) |
| Category | Integrated Circuits (ICs) > Interface ICs > Geode Companion Chip |
| Description | Geode companion chip designed for AMD Geode processor platform, integrates display interface, PCI bridge, memory control and peripheral management, BGA package, industrial temperature grade. |
| Stock Status | In Stock |
| Origin | Original Factory |
Product Overview
CS5530A-UCE is AMD’s companion control chip produced by National Semiconductor, matched for Geode embedded CPUs. It integrates PCI bridge, display controller and SDRAM memory unit in one chip, simplifying embedded mainboard design. Supporting wide industrial temperature range, it’s widely used in touch panels, POS machines and fanless industrial control equipment.
Core Advantages
High Integration for Geode Platform
Integrates PCI, memory and display circuits to reduce peripheral devices and PCB layout difficulty.
Stable Industrial Temperature Grade
Wide temperature design ensures long-term stable operation in harsh industrial environments.
Complete Peripheral Expansion Support
Compatible with standard PCI, LCD and SDRAM hardware, flexible for diverse embedded projects.
Low Power Embedded Architecture
Low-power design matches Geode CPU, saving power for battery and fanless control devices.
Key Specifications
| Brand | AMD Geode Embedded Companion Chip Series |
|---|---|
| Full Part Number | CS5530A-UCE |
| Manufacturer | AMD (Manufactured by National Semiconductor / NS) |
| RoHS Status | RoHS Compliant / Lead-Free / Green Materials Verified (“-E” Suffix) |
| Tape & Reel Packaging | Standard factory tape reel packaging available |
| EDA/CAD Model | 3D STEP Models, Schematic Symbols, and Pinout Footprint Configurations available upon request |
| Warranty | 1-Year Standard Quality Warranty |
| Package / Case | PBGA-352 |
| Mounting Type | Surface Mount |
| Surface Marking / Silkscreen | CS5530A-UCE Marking |
| Main Function | Geode CPU companion chip, PCI bridge + memory + display controller |
| Supported Memory | Compatible with standard SDRAM storage |
| Bus Interface | PCI standard bus, dedicated Geode CPU internal bus |
| Analog Supply Voltage | +5 V nominal analog supply rail |
| Digital Supply Voltage | 3.0 V ~ 5.0 V flexible digital logic supply range |
| Operating Temperature Range | -40°C to +85°C Extended Industrial Operational Limits (TA) |
| Storage Temperature | -55°C ~ +125°C |
| Product Grade | Industrial Grade |
| Application Field | Embedded Industrial Control, POS Terminal, Fanless SBC, Digital Signage |
| Batch Date Code Range | 10+, 13+, 2000+ factory production batches in stock |
Typical Applications
- Industrial control single board computers, embedded touch screen industrial panels
- Commercial POS cash registers, self-service vending terminal mainboards
- Fanless low-power embedded digital signage, advertising display equipment
- Transportation vehicle embedded control host, onboard industrial display unit
- Medical embedded control equipment, compact industrial automation controllers
Order & Shipping Info
| Minimum Order Quantity (MOQ) | 1 Piece |
|---|---|
| Shipping Time | Shipped within 1-2 business days |
| Delivery Time | 3-7 working days worldwide |
| Shipping Methods | DHL, UPS, FedEx, EMS |
| Payment Methods | T/T (Bank Transfer), PayPal, Credit Card, Western Union |
Technical Support
Send datasheet requests, sample demands, stock checks & bulk quotations via Quick Inquiry. We reply within 24 hours.
Frequently Asked Questions
Q1: Are your CS5530A-UCE 100% new original?
A1: Yes. All chips are factory-original brand new, packed in anti-static vacuum packaging to avoid ESD damage for SMT assembly.
Q2: What’s the difference between AMD CS5530A-UCE and Cirrus Logic CS5530?
A2: They are completely different chips. CS5530A-UCE is AMD Geode BGA companion chip; Cirrus CS5530 is SSOP ADC with no correlation.
Q3: What does suffix UCE stand for?
A3: UC = industrial temp range -40℃~+85℃; E = lead-free, RoHS compliant for export.
Q4: Is TI the manufacturer of CS5530A-UCE?
A4: No. Designed by AMD, manufactured by NS. TI acquired NS but did not take over this Geode chip line.
Q5: Can I order samples for testing?
A5: Yes, small sample orders are supported. Submit inquiry to get sample cost and shipping details.
Q6: What’s your MOQ & delivery time?
A6: No strict MOQ for in-stock batches. Goods ship within 1-2 working days after payment.
Q7: Do you provide BOM kitting service?
A7: Yes. Send your full BOM list, we can match all needed components with one quotation.
Q8: What shipping methods do you offer?
A8: DHL, FedEx, UPS and sea freight are optional for different order volumes.
