DRV8701ERGER
DRV8701ERGER
| Part Number | DRV8701ERGER |
|---|---|
| Manufacturer | Texas Instruments (TI) |
| Category | Motor Drivers; Single H-Bridge Pre-Drivers |
| Description | Single H-Bridge Pre-Driver, 4.9V-60V, PWM Control, Current Sense, VQFN-24 Package |
Product Overview
The DRV8701ERGER is a highly integrated single H-bridge pre-driver designed for driving external N-channel power MOSFETs in brushed DC motor and solenoid control applications. It supports a wide input voltage range from 4.9V to 60V and features programmable gate drive, current regulation, and comprehensive protection mechanisms. The device includes integrated current sensing, overcurrent protection, undervoltage lockout, and thermal shutdown to ensure safe and reliable operation. With its compact VQFN-24 surface-mount package, it enables high-efficiency, high-power motor drive designs for industrial, automotive, and robotics systems.
| Key Specifications | |
|---|---|
| RoHS Status | RoHS Compliant |
| EDA / CAD Models | 3D Model, Symbol, Footprint Available |
| Warranty | 2-Year Warranty |
| Brand | Texas Instruments (TI) |
| Supply Voltage | 4.9V ~ 60V |
| Control Interface | PWM / Phase & Enable |
| Features | Integrated Current Sense, Programmable Gate Drive |
| Package Type | VQFN-24 |
| Operating Temperature | -40°C to +125°C |
Typical Applications
- Brushed DC Motor Drive Systems
- Industrial Automation & Machinery
- Robotics & Actuator Control
- Automotive Motor Controls
- Solenoid & Valve Control
- High-Voltage Power Drive Modules
- Factory Automation Equipment
- Portable & Industrial Power Tools
