EPM7032SLC44-10N
EPM7032SLC44-10N
| Part Number | EPM7032SLC44-10N |
|---|---|
| Manufacturer | Altera (Intel® Programmable Solutions Group) |
| Category | Integrated Circuits (ICs) – CPLDs (Complex Programmable Logic Devices) |
| Description | EPM7032SLC44-10N MAX®7000S Series CPLD, 32 Macrocells, 10ns tPD, 44-PLCC, 5V Non-Volatile ISP Complex Programmable Logic Device, Obsolete |
| Stock Status | In Stock |
| Origin | Original Factory New |
Product Overview
The The EPM7032SLC44-10N is a MAX® 7000S series CPLD from Altera (Intel). Adopting non-volatile EEPROM technology, it supports JTAG in-system programmability (ISP). It contains 32 macrocells divided into 2 LABs, with 10 ns maximum propagation delay and up to 125 MHz clock frequency.This device is officially obsolete. It is suitable for legacy equipment maintenance. MAX 10 or Cyclone series are recommended for new designs.
Core Advantages
In-System Programmability (ISP)
IEEE 1149.1 JTAG interface enables on-board programming without removing the chip.
High-Speed Performance
10.0 ns max propagation delay, supporting clock frequency up to 125 MHz.
Non-Volatile EEPROM
Configuration data saved permanently, no external boot memory required.
Stable Timing
Fixed routing delays simplify timing analysis for digital designs.
Rich I/O Resources
36 bidirectional I/O pins in 44-PLCC package for diverse interface applications.
Adjustable Power Mode
Programmable low-power mode reduces static power consumption.
Key Specifications
| Brand | Altera / Intel® |
|---|---|
| RoHS Status | RoHS Compliant / Lead-Free |
| EDA / CAD Models | Symbol, Footprint & 3D Model Available |
| Warranty | 365 Days Quality Guarantee |
| Package / Case | 44-LCC (J-Lead) / 44-PLCC (16.59mm × 16.59mm) |
| Mounting Type | Surface Mount (SMT) |
| Surface Marking / Silkscreen | EPM7032SLC44-10N Marking |
| Programmable Type | In-System Programmable (ISP) via JTAG |
| Number of Macrocells | 32 |
| Number of Logic Blocks (LABs) | 2 |
| Maximum Propagation Delay tpd(1) | 10.0 ns |
| Max Supported Clock Frequency | 125 MHz |
| Voltage Supply – Internal | 4.75 V ~ 5.25 V (Nominal 5.0 V) |
| Number of I/O Pins | 36 Bidirectional I/O |
| Operating Temperature | 0°C ~ 70°C (Commercial Grade TA) |
| Memory Type | EEPROM (Non-Volatile) |
| Lifecycle Status | Obsolete / Discontinued by Manufacturer |
Typical Applications
- Legacy Equipment Maintenance & Repair
- Industrial Control & Automation Systems
- Legacy Bus Bridging & Interface Decoding Logic
- Telecom & Datacom Communications Hardware
- Embedded Microcontroller Peripheral Expansion
- State Machine Control & High-Speed Timing Generation
- Glue Logic Integration in Consumer & Medical Electronics
Order & Shipping Info
| Minimum Order Quantity (MOQ) | 1 Piece |
|---|---|
| Shipping Time | Shipped within 1-2 business days |
| Delivery Time | 3-7 working days worldwide |
| Shipping Methods | DHL, UPS, FedEx, EMS |
| Payment Methods | T/T (Bank Transfer), PayPal, Credit Card, Western Union |
Technical Support
Frequently Asked Questions
Q: Is the EPM7032SLC44-10N original and genuine?
A: Yes, we guarantee all supplied EPM7032SLC44-10N are 100% authentic stock with full traceability.
Q: What does each segment of part number EPM7032SLC44-10N stand for?
A: EPM = Erasable Programmable Macrocell; 7032 = MAX7000 family with 32 macrocells; S = MAX7000S series (ISP supported); LC = LCC/PLCC package; 44 = 44 pins; 10 = 10ns speed grade; N = Lead-free RoHS compliant.
Q: What software can be used to program this CPLD?
A: The EPM7032SLC44-10N can be programmed with Altera Quartus II or MAX+PLUS II software, matched with USB-Blaster or ByteBlaster download cable.
Q: Is EPM7032SLC44-10N suitable for new electronic design projects?
A: This component is officially discontinued (obsolete). It is mainly used for legacy equipment maintenance. For new projects, we recommend MAX 10 or Cyclone series alternatives. Contact us for cross-reference suggestions.
Q: What is the operating voltage range of EPM7032SLC44-10N?
A: Internal operating voltage: 4.75V ~ 5.25V, nominal 5V power supply.
Q: What is the operating temperature range for this chip?
A: Commercial temperature grade: 0°C ~ 70°C, not recommended for industrial wide temperature applications.
Q: Does this chip retain program data after power off?
A: Yes. It adopts EEPROM non-volatile technology, configuration data will not be lost after power failure.
Q: Can I perform in-system programming (ISP) on the PCB?
A: Supported. Standard JTAG interface allows on-board programming without removing the chip from the circuit board.
Q: Do you offer bulk discounts and pre-shipment testing reports?
A: Yes. We provide tier pricing for bulk orders and functional testing reports upon request. Please submit an inquiry for formal quotation.
Q: How long is the delivery time after placing an order?
A: In-stock items can be shipped within 1-2 working days. Global delivery normally takes 3~7 working days depending on shipping method.
