| Part Number | H11L1M |
|---|---|
| Manufacturer | Fairchild Semiconductor / ON Semiconductor |
| Category | Optoisolators; Logic Output Optocouplers |
| Description | High-Speed Logic Gate Optocoupler, 1MBd Data Rate, Open-Collector Output,3V~15V, DIP-6 Package |
Product Overview
The H11L1M is a high-speed optically coupled logic gate isolator designed for digital signal isolation in industrial, power, and communication systems. It features an integrated LED input and a high-speed photodetector output with open-collector logic configuration, providing galvanic isolation between input and output circuits to protect sensitive control systems from high voltage, noise, and ground loops. The device supports up to 1MBd data rate, TTL/LSTTL/CMOS compatibility, and high isolation voltage, making it ideal for high-speed digital isolation, signal conditioning, and noise rejection in harsh industrial environments. Housed in a standard DIP-8 through-hole package, it enables easy PCB assembly and reliable long-term operation.
| Key Specifications | |
|---|---|
| RoHS Status | RoHS Compliant |
| EDA / CAD Models | 3D Model, Symbol, Footprint Available |
| Warranty | 2-Year Warranty |
| Brand | ON Semiconductor |
| Data Rate | 1 MBd |
| Isolation Voltage | 5000 Vrms |
| Package Type | DIP-6 |
| Operating Temperature | -40°C to +85°C |
Typical Applications
- High-Speed Digital Signal Isolation
- Industrial Control & PLC Systems
- Microcontroller I/O Isolation
- Power Supply Feedback & Regulation
- Ground Loop Noise Elimination
- TTL/CMOS/Logic Level Isolation
- Motor Drive & Inverter Systems
- High-Voltage Digital Interface Protection
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
