HR8P506FHLQ
HR8P506FHLQ
| Part Number | HR8P506FHLQ |
|---|---|
| Manufacturer | Qingdao Eastsoft Intelligent Electronics Co., Ltd. (Eastsoft) |
| Category | Integrated Circuits (ICs) > Embedded – Microcontrollers |
| Description | High-performance 32-bit ARM Cortex-M0 microcontroller with integrated high-precision analog peripherals, multi-channel timers, flexible communication interfaces, strong industrial noise immunity, packaged in LQFP-48. |
| Stock Status | In Stock |
| Origin | Original Factory |
Product Overview
The HR8P506FHLQ is a cost-effective 32-bit Cortex-M0 MCU from Eastsoft for embedded control products. Running up to 48MHz, it carries 36KB Flash and 8KB SRAM, integrated 16-channel 12-bit ADC, multi-way timers/PWM, UART/SPI/I2C and LCD drive circuit. Equipped with industrial EMC and ESD protection, it operates steadily in noisy electrical environments. The LQFP-48 package with 46 IOs fits smart home, motor control, LED lighting and power management hardware perfectly.
Core Advantages
High-Efficiency 32-Bit Processing Performance
ARM Cortex-M0 core delivers higher operation efficiency than traditional 8/16-bit MCUs, capable of complex control algorithms with low system overhead.
Rich On-Chip Analog Integration
Built-in 16-channel 12-bit ADC and comparators reduce external discrete components, lower total BOM cost and PCB layout area.
Exceptional Anti-Interference and ESD Robustness
Industrial-grade noise filtering and ESD protection on all IOs, stable operation under switching power supply and electromagnetic interference.
Highly Adaptable Peripheral Routing
Multi-channel PWM for motor & power regulation, plus 3×UART, 2×SPI, 1×I2C to support diverse peripheral expansion.
Key Specifications
| Brand | Eastsoft® HR8P 32-Bit Cortex-M0 Microcontroller Series |
|---|---|
| RoHS Status | RoHS Compliant / Lead-Free / Halogen-Free Materials Sourced and Approved |
| EDA/CAD Model | 3D STEP Models, Schematic Symbols, and PCB footprints available upon request |
| Warranty | 1-Year Standard Quality Warranty |
| Package / Case | LQFP-48 (7×7×0.5mm) |
| Mounting Type | Surface Mount Technology (SMD/SMT Lead Reflow Solder Assembly) |
| Package Tape Spec | Standard tape & reel packaging, 250 pieces per tray |
| Surface Marking / Silkscreen | HR8P506FHLQ Marking |
| I/O Pins Count | 46 Configurable General Purpose I/O Pins |
| Core Processing Core | 32-bit ARM® Cortex™-M0 Processor Core |
| Maximum Operating Frequency | Up to 48 MHz Nominal Dynamic System Execution Speed |
| Program Memory (Flash) | 36KB High-reliability Embedded Code Flash Memory |
| Data Memory (SRAM) | 8KB Integrated High-Speed SRAM array for variable cache |
| Clock Source | Internal 24MHz RC oscillator, supports external crystal oscillator |
| Communication Interfaces | 3×UART, 2×SPI, 1×I2C Serial Communication Ports |
| Analog Converter Subsystem | 16-Channel 12-bit High-Speed Analog-to-Digital Converter (ADC) Matrix |
| Timer & PWM Modules | 4×16-bit + 1×32-bit Multi-Mode Timers, Dead-Time Configurable PWM Outputs |
| Integrated Special Modules | On-chip RTC Real-Time Clock, LCD Segment Drive Circuit, Hardware Self-Test |
| Brown-out Detection | Built-in programmable power brown-out reset circuit for undervoltage protection |
| ESD Protection Level | All IO pins support ±8kV contact ESD industrial protection |
| Operating Voltage Supply | 2.2V ~ 5.5V Wide continuous operational voltage range for industrial power rails |
| Operating Temperature Range | -40°C ~ +85°C Industrial Grade Thermal Operation Certified |
Typical Applications
- Smart Home Consumer Appliances, Touch-Control Control Panels, and Kitchen Electronic Systems
- Industrial Motor Control Modules, Small BLDC Motor Drivers, and Electric Ventilator Fans
- Intelligent LED Lighting Controls, Architectural Lighting Arrays, and Digital Dimmers
- Power Management Sub-Modules, Battery Charger Infrastructure, and Auxiliary Power Boards
- Distributed IoT Sensor Transmitters, Security Monitoring Transceivers, and Embedded Gauges
Order & Shipping Info
| Minimum Order Quantity (MOQ) | 1 Piece |
|---|---|
| Shipping Time | Shipped within 1-2 business days |
| Delivery Time | 3-7 working days worldwide |
| Shipping Methods | DHL, UPS, FedEx, EMS |
| Payment Methods | T/T (Bank Transfer), PayPal, Credit Card, Western Union |
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
Frequently Asked Questions
Q1: Is your currently available stock of the HR8P506FHLQ 100% original and genuine?
A: Yes, all HR8P506FHLQ MCUs are brand-new original Eastsoft factory stock. Each batch passes strict incoming inspection and stored in anti-static moisture-proof trays to protect LQFP pins from oxidation and damage.
Q2: What is the computational advantage of the HR8P506’s ARM Cortex-M0 core compared to standard 8-bit MCUs?
A: The 32-bit Cortex-M0 core provides higher arithmetic efficiency and faster operation speed. It runs complex multi-loop control logic at lower clock frequency and reduces overall system power consumption.
Q3: How does the HR8P506FHLQ handle harsh industrial electronic noise and voltage fluctuations?
A: This MCU adds internal clock noise filters, high ESD protection on IOs and brown-out reset circuit. It prevents abnormal code execution caused by voltage ripple and electromagnetic interference in industrial equipment.
Q4: How can our physical engineering group secure the programming user guides or request a high-volume pricing quote?
A: Fill the Quick Inquiry form on this page with project specs and order quantity. Our embedded technical team will send official datasheets, register manuals and customized bulk price within 24 hours.
