IMX283CQJ-C
IMX283CQJ-C
| Part Number | IMX283CQJ-C |
|---|---|
| Manufacturer | Sony Semiconductor Solutions |
| Category | Sensors, Transducers > Image Sensors, Camera Modules |
| Description | Type 1.0 (Diagonal 15.86 mm) 20.30 MP CMOS Active Pixel Solid‑State Image Sensor, Exmor‑R Back‑Illuminated, QFN‑style Ceramic LGA Package, Industrial Grade Bare Die Sensor. |
| Stock Status | In Stock |
| Origin | Original Factory |
Product Overview
The IMX283CQJ‑C is a 20.30‑megapixel Type 1.0 CMOS image sensor with Sony Exmor‑R back‑illuminated architecture. This industrial bare‑die sensor features 4‑lane MIPI CSI‑2 and I²C control interface, delivering 25 fps at full resolution. Higher frame rates are achievable via binning or sub‑sampling. It targets industrial machine vision, scientific imaging and drone mapping applications, and is not a finished camera module.
Core Advantages
Exmor‑R Back‑Illuminated Pixel
Back‑illuminated CMOS design offers high sensitivity and low dark‑noise for complex lighting conditions.
Type 1.0 Large‑Format 20.3MP Resolution
5472×3648 resolution with 2.4 µm pixels, providing fine details for industrial inspection.
MIPI CSI‑2 + I²C Interface
4‑lane MIPI CSI‑2 output with I²C register configuration. SLVS‑EC is not supported.
Flexible Rolling Shutter Readout
Rolling shutter with adjustable integration time, supports binning and sub‑sampling for higher frame‑rate.
Industrial Bare‑Die Ceramic LGA Package
QFN‑style ceramic LGA bare‑die chip for custom industrial imaging designs, excluding lens and ISP.
Key Specifications
| Brand | Sony |
|---|---|
| RoHS Status | RoHS Compliant / Lead‑Free |
| EDA / CAD | PCB Footprint & 3D Model Available upon Request |
| Warranty | 1‑Year Standard Quality Warranty |
| Package / Case | QFN‑style 118‑Pin Ceramic LGA Bare‑Die Package |
| Mounting Type | Surface Mount (SMD / SMT) |
| Surface Marking / Silkscreen | IMX283CQJ |
| Active Array Size | 5472 (H) x 3648 (V), approx. 20.30 Megapixels |
| Optical Format | Type 1.0 (Diagonal 15.86 mm) |
| Pixel Size | 2.4 µm (H) x 2.4 µm (V) |
| Maximum Frame Rate | 25 fps at full resolution; higher‑fps output under binning / sub‑sampling mode |
| Output Interface | 4‑Lane MIPI CSI‑2 + I²C Control; SLVS‑EC is not supported |
| Power Supply Voltages | Analog: 2.9V / Digital: 1.2V / Interface: 1.8V |
| Operating Temperature Range | ‑10°C ~ +75°C (functional);‑10°C ~ +60°C for rated performance |
| Storage Temperature Range | ‑30°C ~ +80°C |
| Shutter Type | Rolling Shutter |
| Output Bit Depth | 9‑bit / 10‑bit / 12‑bit RAW |
Typical Applications
- High‑Precision Industrial Machine Vision and Automated Inspection Systems
- High‑Resolution Scientific Instruments and Medical Imaging Equipment
- High‑End Security Surveillance Imaging
- Intelligent Traffic Monitoring and Automatic Number Plate Recognition (ANPR)
- Robotics Vision Guidance and High‑Performance Aerial Mapping Drones
Order & Shipping Info
| Minimum Order Quantity (MOQ) | 1 Piece |
|---|---|
| Shipping Time | Shipped within 1‑2 business days |
| Delivery Time | 3‑7 working days worldwide |
| Shipping Methods | DHL, UPS, FedEx, EMS |
| Payment Methods | T/T (Bank Transfer), PayPal, Credit Card, Western Union |
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
Frequently Asked Questions
Q1: What is the pixel resolution and optical format of IMX283CQJ‑C?
A1: Type 1.0 optical format (15.86 mm diagonal), 5472×3648 effective pixels, 20.30 MP.
Q2: What core technology does IMX283CQJ‑C adopt?
A2: Sony Exmor‑R back‑illuminated CMOS. It is rolling‑shutter, not global‑shutter type.
Q3: What interfaces are supported by IMX283CQJ‑C?
A3: 4‑lane MIPI CSI‑2 + I²C for register configuration. SLVS‑EC is not supported.
Q4: What does suffix ‑C mean? Difference vs IMX283CQJ?
A4: ‑C denotes industrial‑grade bare‑die ceramic LGA variant. IMX283CQJ‑C and IMX283CQJ share identical pixel parameters, differ only in packaging and grade. It is not a finished camera module.
Q5: What is the full‑resolution maximum frame rate?
A5: 25 fps at full resolution. Higher frame‑rate is available via binning or sub‑sampling cropping.
Q6: What are operating and storage temperature ranges?
A6: Functional:‑10℃ ~ +75℃; rated performance:‑10℃ ~ +60℃. Storage:‑30℃ ~ +80℃.
Q7: What are alternative compatible sensor models?
A7: Similar options: IMX455, IMX541. No pin‑to‑pin drop‑in replacement. Alternatives require full PCB redesign, ISP tuning and driver modification.
Q8: Is IMX283CQJ‑C a complete camera module?
A8: No. It is bare‑die sensor chip only, without lens or ISP. Users need to design peripheral hardware separately.
Q9: How to get datasheet and volume pricing?
A9: Submit Quick Inquiry form for datasheet, register reference, stock status and volume quotation.
