JMD330-LGAA1D
JMD330-LGAA1D
| Part Number | JMD330-LGAA1D |
|---|---|
| Manufacturer | JMicron Technology Corporation |
| Category | Integrated Circuits (ICs) > Interface – Controllers / Storage Bridge Controllers |
| Description | High-performance SATA Gen1 to Parallel ATA (PATA/IDE) storage bridge controller IC with native hardware protocol translation, low power consumption, full ATAPI drive support, packaged in lead-free TQFP-64. |
| Stock Status | In Stock |
| Origin | Original Factory New & Genuine |
Product Overview
The JMD330-LGAA1D is JMicron’s single-chip SATA Gen1 to PATA/IDE storage bridge IC. It uses pure hardware logic to translate SATA host signals for legacy IDE HDDs, SSDs and ATAPI optical drives, with plug-and-play operation without extra drivers. Supporting full PIO/DMA/Ultra DMA 133 modes, it integrates an 8KB bidirectional FIFO buffer and stable SATA PHY. Packaged in compact TQFP-64 with low-power design, this commercial-grade chip serves legacy storage upgrades, external optical drive enclosures and industrial embedded interface conversion.
Core Advantages
Pure Hardware SATA-to-PATA Transparent Conversion
All protocol conversion is completed by on-chip hardware logic without any driver or firmware setup, realizing fully transparent SATA Gen1 to PATA/IDE signal bridging with broad cross-system compatibility.
Full ATAPI Peripheral Compatibility
Supports standard ATA hard disks, SSDs and complete ATAPI packet command sets, perfectly compatible with CD-ROM, DVD-ROM, DVD-RW and tape storage devices.
Low Power & Stable Continuous Operation
Optimized clock gating and low-voltage circuit design effectively reduce power consumption and heat output, suitable for long-term stable operation in compact embedded equipment.
Complete PATA High-Speed Transfer Support
Covers all mainstream transmission standards including PIO mode 0-4, Multi-Word DMA 0-2 and Ultra DMA 33/66/100/133, realizing stable maximum transmission bandwidth of 150MB/s.
Key Specifications
| Brand | JMicron Technology Storage Bridge Series |
|---|---|
| RoHS Status | RoHS Compliant / Lead-Free / Green Manufacturing Standards Qualified |
| EDA/CAD Model | 3D STEP Models, Schematic Symbols, and PCB Pin-Out Footprints available upon request |
| Warranty | 1-Year Standard Quality Warranty |
| Package / Case | TQFP-64 |
| Mounting Type | Surface Mount Technology (SMD/SMT) |
| Surface Marking / Silkscreen | JMD330-LGAA1D Marking |
| Core Bridge Topology | Serial ATA (SATA Gen1) to Parallel ATA (PATA / IDE) Hardware Bridge |
| SATA Physical Interface | 1 Port SATA PHY, supporting SATA 1.5 Gbps communication rates |
| SATA Max Transfer Bandwidth | 150 MB/s theoretical maximum throughput |
| PATA Bus Transfer Standards | Ultra DMA 33/66/100/133, Multi-Word DMA Modes 0/1/2, and PIO Modes 0 through 4 |
| Supported Drive Categories | Hard Disk Drives (HDD), Solid State Drives (SSD), and CD-ROM/DVD-ROM/DVD-RW Optical ATAPI Devices |
| Master/Slave Configuration | Supports single Master or Slave PATA routing selections via hardware strapping pins |
| Clock Reference Configuration | Supports cost-effective external crystal oscillator configurations |
| Standard Crystal Frequency | 25 MHz external crystal oscillator |
| On-Chip Data Buffer | 8KB integrated bidirectional FIFO data buffer |
| Operating Supply Voltage | Core: 1.8 V; I/O Interface: 3.3 V |
| Hardware Built-in Function | Hot-plug detection, power management control, error correction circuit |
| Storage Channel Count | 1 × SATA host channel, 1 × PATA device channel |
| Operating Temperature Range | 0°C to +70°C (Standard Commercial Grade) |
Typical Applications
- External Optical Disk Drive (ODD) Enclosures, CD-RW/DVD-RW docking stations and multimedia recording devices
- Legacy embedded host upgrade, industrial single-board computer (SBC) and old-generation PC storage interface renovation
- Industrial data acquisition equipment, CNC mainboard interface conversion and medical storage peripheral modules
- Hard drive duplicator controllers, industrial test bench adapters and storage subsystem signal conversion boards
- Self-service kiosk equipment, vintage industrial hosts and professional data archiving terminal devices
Order & Shipping Info
| Minimum Order Quantity (MOQ) | 1 Piece |
|---|---|
| Shipping Time | Shipped within 1-2 business days |
| Delivery Time | 3-7 working days worldwide |
| Shipping Methods | DHL, UPS, FedEx, EMS |
| Payment Methods | T/T (Bank Transfer), PayPal, Credit Card, Western Union |
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
Frequently Asked Questions
Q1: Is your currently available stock of the JMD330-LGAA1D bridge controller 100% genuine and original?
A: Yes, we guarantee that all JMD330-LGAA1D integrated circuits in our warehouse are 100% brand-new, factory-original components directly from JMicron Technology Corporation. Every batch passes internal tracking audits and is shipped inside secure anti-static protective packaging to keep the QFP leads pristine.
Q2: Does the JMD330-LGAA1D require custom firmware or a special software driver to connect IDE drives to SATA motherboards?
A: No, it does not. The JMD330-LGAA1D features automatic hardware conversion on the silicon die. It converts SATA host signals to PATA/IDE signals natively; legacy IDE/PATA or ATAPI drives are recognized as standard SATA devices by the system. No custom drivers, software utilities, or code installations are needed.
Q3: Can the JMD330-LGAA1D support ATAPI devices like optical DVD recorders or is it limited to hard drives?
A: This chip fully supports both standard ATA hard drives, SSDs and ATAPI optical peripherals. It completely parses and converts ATAPI packet commands, supporting normal reading and writing of CD/DVD optical drives and tape storage equipment.
Q4: How can our technical engineering division request a comprehensive component data sheet or bulk volume quotes?
A: Please complete the Quick Inquiry web form found directly on this webpage. Our technical support representatives will review your project requirements and respond with complete data packages and custom commercial pricing within 24 hours.
