LFCG-3400+
LFCG-3400+
| Part Number | LFCG-3400+ |
| Manufacturer | Mini-Circuits |
| Category | RF Components > RF Filters > Low Pass Ceramic RF Filter |
| Description | Surface Mount Low Pass Filter, DC~3400MHz Cutoff Frequency, RF Harmonic Suppression Component,insertion loss 0.09dB,SMD-8P,2×1.2mm Package |
Product Overview
The LFCG-3400+ is a compact surface mount low-pass RF filter manufactured by Mini-Circuits with 3400MHz cutoff frequency. Constructed with high-performance multilayer ceramic technology, this component features low insertion loss within passband, high stopband rejection and excellent signal suppression for out-of-band harmonic and spurious interference signals. Small-sized SMD outline is compatible with automatic SMT soldering process, delivering stable electrical performance across wide operating temperature range. It is extensively used for RF harmonic filtering, LO noise suppression and signal purification in wireless transceiver modules, test instrumentation and various RF communication circuits.
Key Specifications
| Brand | Mini-Circuits |
| RoHS | RoHS Compliant |
| EDA / CAD | Symbols, Footprints, 3D Models Available |
| Warranty | 1 Year Standard Warranty |
| Package / Case | SMD-8P,2×1.2mm Package |
| Mounting Type | Surface Mount |
| Surface Marking / Silkscreen | LFCG-3400+ |
| Cutoff Frequency | 3400MHz |
| Passband Range | DC ~ 3400MHz |
| Typical Insertion Loss | Low Insertion Loss In Passband |
| Impedance | 50 Ohm Standard RF Impedance |
| Operating Temperature | -40°C ~ 85°C |
Typical Applications
- Wireless RF Transceiver Harmonic Suppression Filtering
- Test & Measurement Instrument RF Signal Conditioning
- IoT Wireless Module Out-of-Band Spurious Elimination
- Broadband Receiver Front-End Low Pass Filter Circuits
- SDR Software Defined Radio Signal Purification Module
- RF Power Amplifier Output Harmonic Filter Unit
- Cellular Communication RF Matching & Filter Board
- Microwave Test Bench Low Pass Filter Components
Order & Shipping Info
Minimum Order Quantity (MOQ): 1 Piece
Shipping Time: Shipped within 1-2 business days
Delivery Time: 3-7 working days worldwide
Shipping Methods: DHL, UPS, FedEx, EMS
Payment Methods: T/T (Bank Transfer), PayPal, Credit Card, Western Union
Technical Support
Frequently Asked Questions
Q1: Is LFCG-3400+ RoHS compliant?
A: Yes, this product fully complies with RoHS environmental standards.
Q2: Can I apply for product samples for testing?
A: Sample service is available, please submit your request via the Quick Inquiry form.
Q3: What is the package and mounting type?
A: It adopts miniature ceramic SMD-8P,2×1.2mm package and surface mount type for PCB assembly.
Q4: What is the typical insertion loss of LFCG-3400+ within passband?
A: The component owns low typical insertion loss in DC~3400MHz passband:0.09dB, which guarantees little signal attenuation during RF transmission and ensures stable circuit performance.
