LFCN-1000+
LFCN-1000+
| Part Number | LFCN-1000+ |
|---|---|
| Manufacturer | Mini-Circuits |
| Category | RF Filters; Low Pass Filter |
| Description | 50Ω RF Low Pass Filter, 1000 MHz Cutoff Frequency,10W, Surface Mount, SMD-4P,3.2×1.6mm Package Type |
Product Overview
The LFCN-1000+ is a high-performance, RoHS-compliant ceramic RF low pass filter designed by Mini-Circuits for professional wireless communication, RF signal conditioning, and high-frequency applications. It features a precise 1000 MHz cutoff frequency, standard 50Ω impedance, ultra-low insertion loss, high stopband attenuation, and excellent temperature stability. The device delivers consistent RF performance, rugged ceramic construction, and reliable operation in commercial, industrial, and telecommunication systems. Encased in a compact surface-mount package, it supports high-density PCB integration and automated SMT assembly processes.
| Key Specifications | |
|---|---|
| Brand | Mini-Circuits |
| RoHS Status | RoHS Compliant |
| EDA / CAD Models | 3D Model, Symbol, Footprint Available |
| Warranty | 2-Year Warranty |
| Package / Case | SMD-4P,3.2×1.6mm Package |
| Mounting Type | Surface Mount (SMD) |
| Surface Marking / Silkscreen | LFCN-1000 |
| Cutoff Frequency | 1000 MHz |
| Impedance | 50 Ohms |
| Operating Temperature | -40°C to +85°C |
Typical Applications
- RF Communication Systems
- Wireless Transceiver Modules
- Signal Conditioning & Noise Filtering
- Test & Measurement Equipment
- Industrial RF Control Circuits
- Broadcast RF Equipment
- High-Frequency Data Transmission
- Consumer Electronic RF Devices
Order & Shipping Info
Minimum Order Quantity (MOQ): 1 Piece
Shipping Time: Shipped within 1-2 business days
Delivery Time: 3-7 working days worldwide
Shipping Methods: DHL, UPS, FedEx, EMS
Technical Support
For datasheet, sample requests, stock check, or bulk pricing, please use the Quick Inquiry form. We will reply within 24 hours.
